SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BACK LIGHT MAIN
1-674-798-11 BACK LIGHT BOARD
****************
< CONNECTOR >
CN605 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< LED >
D639 8-719-076-15 LED SELS6B14C-TP6 (LCD BACK LIGHT)
D640 8-719-076-15 LED SELS6B14C-TP6 (LCD BACK LIGHT)
D641 8-719-076-15 LED SELS6B14C-TP6 (LCD BACK LIGHT)
D642 8-719-076-15 LED SELS6B14C-TP6 (LCD BACK LIGHT)
< TRANSISTOR >
Q639 8-729-900-36 TRANSISTOR BA1F4M-TP
Q640 8-729-900-36 TRANSISTOR BA1F4M-TP
< RESISTOR >
R639 1-249-403-11 CARBON 68 5% 1/4W
R640 1-249-403-11 CARBON 68 5% 1/4W
R670 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
A-4426-230-A MAIN BOARD, COMPLETE (NX1: AEP, UK)
A-4426-242-A MAIN BOARD, COMPLETE (NX1: US, CND)
A-4426-251-A MAIN BOARD, COMPLETE (NX1: MY, SP)
A-4426-261-A MAIN BOARD, COMPLETE (NX3: AEP, UK)
A-4426-269-A MAIN BOARD, COMPLETE (NX3: US, CND)
A-4426-277-A MAIN BOARD, COMPLETE (NX3: MY, SP)
A-4426-527-A MAIN BOARD, COMPLETE (NX3: KR, AUS)
A-4426-556-A MAIN BOARD, COMPLETE (NX1: JE)
A-4426-559-A MAIN BOARD, COMPLETE (NX1: KR)
A-4426-931-A MAIN BOARD, COMPLETE (NX1: TH)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-162-286-31 CERAMIC 220PF 10% 50V
C102 1-162-286-31 CERAMIC 220PF 10% 50V
C103 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-164-159-11 CERAMIC 0.1uF 50V
(US, CND, AEP, UK)
C111 1-137-195-11 FILM 0.56uF 5% 50V
C112 1-136-158-00 FILM 0.027uF 5% 50V
C113 1-136-167-00 FILM 0.15uF 5% 50V
C114 1-137-437-11 FILM 0.0056uF 5% 50V
C115 1-136-159-00 FILM 0.033uF 5% 50V
C116 1-137-365-11 FILM 0.0015uF 5% 50V
C117 1-136-153-00 FILM 0.01uF 5% 50V
C118 1-162-288-31 CERAMIC 330PF 10% 50V
C119 1-137-368-11 FILM 0.0047uF 5% 50V
C120 1-137-367-11 FILM 0.0033uF 5% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-162-291-31 CERAMIC 560PF 10% 50V
C123 1-136-169-00 FILM 0.22uF 5% 50V
C124 1-136-169-00 FILM 0.22uF 5% 50V
C125 1-126-964-11 ELECT 10uF 20% 50V
C127 1-162-306-11 CERAMIC 0.01uF 30% 16V
C128 1-136-495-11 FILM 0.068uF 5% 50V
C131 1-104-664-11 ELECT 47uF 20% 16V
C132 1-104-664-11 ELECT 47uF 20% 16V
C134 1-126-964-11 ELECT 10uF 20% 50V
C141 1-126-959-11 ELECT 0.47uF 20% 50V
C151 1-162-286-31 CERAMIC 220PF 10% 50V
C152 1-162-286-31 CERAMIC 220PF 10% 50V
C153 1-162-286-31 CERAMIC 220PF 10% 50V
C161 1-137-195-11 FILM 0.56uF 5% 50V
C162 1-136-158-00 FILM 0.027uF 5% 50V
C163 1-136-167-00 FILM 0.15uF 5% 50V
C164 1-137-437-11 FILM 0.0056uF 5% 50V
C165 1-136-159-00 FILM 0.033uF 5% 50V
C166 1-137-365-11 FILM 0.0015uF 5% 50V
C167 1-136-153-00 FILM 0.01uF 5% 50V
C168 1-162-288-31 CERAMIC 330PF 10% 50V
C169 1-137-368-11 FILM 0.0047uF 5% 50V
C170 1-137-367-11 FILM 0.0033uF 5% 50V
C171 1-126-964-11 ELECT 10uF 20% 50V
C172 1-162-291-31 CERAMIC 560PF 10% 50V
C173 1-136-169-00 FILM 0.22uF 5% 50V
C174 1-136-169-00 FILM 0.22uF 5% 50V
C175 1-126-964-11 ELECT 10uF 20% 50V
C191 1-162-286-31 CERAMIC 220PF 10% 50V
C201 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C202 1-126-964-11 ELECT 10uF 20% 50V
(NX3)
C204 1-124-465-00 ELECT 0.47uF 20% 50V
(NX3)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AUS : Australian model
CND : Canadian model
JE : Tourist model
KR : Korean model
MY : Malaysia model
SP : Singapore model
TH : Thai model
