Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
40
A-4426-260-A SURROUND AMP BOARD, COMPLETE (NX3)
******************************
< CAPACITOR >
C101 1-128-582-11 ELECT 10uF 20% 100V
C102 1-162-292-31 CERAMIC 680PF 10% 50V
C103 1-162-286-31 CERAMIC 220PF 10% 50V
C104 1-126-967-11 ELECT 47uF 20% 50V
C105 1-136-165-00 FILM 0.1uF 5% 50V
C106 1-136-165-00 FILM 0.1uF 5% 50V
C107 1-128-560-11 ELECT 22uF 20% 100V
C108 1-136-495-11 FILM 0.068uF 5% 50V
C109 1-136-495-11 FILM 0.068uF 5% 50V
C113 1-161-494-00 CERAMIC 0.022uF 25V
C114 1-162-294-31 CERAMIC 0.001uF 10% 50V
C151 1-128-582-11 ELECT 10uF 20% 100V
C152 1-162-292-31 CERAMIC 680PF 10% 50V
C153 1-162-286-31 CERAMIC 220PF 10% 50V
C154 1-126-967-11 ELECT 47uF 20% 50V
C157 1-128-560-11 ELECT 22uF 20% 100V
C158 1-136-495-11 FILM 0.068uF 5% 50V
C159 1-136-495-11 FILM 0.068uF 5% 50V
C181 1-128-582-11 ELECT 10uF 20% 100V
C182 1-162-292-31 CERAMIC 680PF 10% 50V
C183 1-162-286-31 CERAMIC 220PF 10% 50V
C184 1-126-967-11 ELECT 47uF 20% 50V
C188 1-136-495-11 FILM 0.068uF 5% 50V
C189 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
* CN101 1-564-524-11 PLUG, CONNECTOR 9P
< DIODE >
D101 8-719-911-19 DIODE 1SS133T-72
D102 8-719-911-19 DIODE 1SS133T-72
D151 8-719-911-19 DIODE 1SS133T-72
D191 8-719-911-19 DIODE 1SS133T-72
< GROUND TERMINAL >
EPT101 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC101 8-749-015-54 IC STK408-040E
< CONNECTOR >
NO102 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< TRANSISTOR >
Q101 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q103 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q104 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q151 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q181 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W
R102 1-249-437-11 CARBON 47K 5% 1/4W
R103 1-249-411-11 CARBON 330 5% 1/4W
0 R107 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R108 1-220-755-11 METAL 0.22 10% 2W F
R109 1-260-076-11 CARBON 10 5% 1/2W
R110 1-249-437-11 CARBON 47K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W
R112 1-249-431-11 CARBON 15K 5% 1/4W
R113 1-249-441-11 CARBON 100K 5% 1/4W
R114 1-249-421-11 CARBON 2.2K 5% 1/4W
R115 1-249-433-11 CARBON 22K 5% 1/4W
R116 1-249-429-11 CARBON 10K 5% 1/4W
R117 1-249-421-11 CARBON 2.2K 5% 1/4W
R119 1-249-439-11 CARBON 68K 5% 1/4W
0 R120 1-217-637-00 FUSIBLE 1 5% 1/4W F
R121 1-249-433-11 CARBON 22K 5% 1/4W
R130 1-249-435-11 CARBON 33K 5% 1/4W
R151 1-249-417-11 CARBON 1K 5% 1/4W
R152 1-249-437-11 CARBON 47K 5% 1/4W
R153 1-249-410-11 CARBON 270 5% 1/4W
0 R157 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R158 1-220-755-11 METAL 0.22 10% 2W F
R159 1-260-076-11 CARBON 10 5% 1/2W
R160 1-249-437-11 CARBON 47K 5% 1/4W
R161 1-249-417-11 CARBON 1K 5% 1/4W
R162 1-249-431-11 CARBON 15K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
R181 1-249-417-11 CARBON 1K 5% 1/4W
R182 1-249-437-11 CARBON 47K 5% 1/4W
R183 1-249-411-11 CARBON 330 5% 1/4W
0 R188 1-220-755-11 METAL 0.22 10% 2W F
R189 1-260-076-11 CARBON 10 5% 1/2W
R190 1-249-437-11 CARBON 47K 5% 1/4W
R191 1-249-417-11 CARBON 1K 5% 1/4W
R192 1-249-431-11 CARBON 15K 5% 1/4W
R193 1-249-441-11 CARBON 100K 5% 1/4W
**************************************************************
1-674-803-11 TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C951 1-162-306-11 CERAMIC 0.01uF 30% 16V
C952 1-162-306-11 CERAMIC 0.01uF 30% 16V
C953 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P (E, AUS, JE)
< FUSE >
0 F951 1-532-505-31 FUSE T5AL/250V (NX1: MY, SP, JE)
0 F951 1-533-311-11 FUSE, GLASS CYLINDRICAL 8A/250V
(NX3: US, CND)
0 F951 1-533-949-31 FUSE T8AL/250V (NX3: MY, SP)
0 F961 1-533-311-11 FUSE, GLASS CYLINDRICAL 8A/125V
(NX1: US, CND)
0 F961 1-533-949-31 FUSE, CYLINDRICAL T8AL/250V
(EXCEPT US, CND)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
SURROUND AMP TRANS
To Next Page
