Sony STR-V7770 - Unit Overview and Controls; Front Panel Controls

— 3 —
Front Panel
SECTION 1
GENERAL
1 MOVIE button
2 MUSIC button
3 GAME button
4 PLACE button
5 P FILE button
6 EFFECT ON/OFF button
7 OPEN/CLOSE button
8 TUNER BAND button
9 STEREO/MONO button
!º MEMORY button
!¡ KARAOKE PON/MIX button
!™ MIC LEVEL/ECHO VOL dial
!£ MIX MIC1 jack
!¢ GROOVE button
!∞ VOLUME dial
!§ ) + button
!¶ ENTER/NEXT button
!• MULTI JOG STATION dial
!ª 0 – button
@º NON-STOP button
@¡ EDIT button
@™ FLASH button
@£ PLAY MODE button
@¢ REPEAT button
@∞ PHONES jack
@§ LOOP button
@¶ CLOCK/TIMER SET button
@• TIMER SELECT button
@ª FUNCTION button
#º PROLOGIC button
#¡ DSP button
#™ DBFB button
#£ DISPLAY/DEMO button
#¢ I/u (POWER) button
#∞ MIX MIC2 jack
#§ KEY CONTROL (n)
#¶ KEY CONTROL (˜)
123 456
7
8
9
!º
!¡
!™
!£
!¢
#∞
!∞
!¶
!§
@∞
@§
@¶
@•
@ª
#£
#¢
#º
#¶ #§!•
!ª
@¡
@£
@¢
@º
#¡
#™
@™
Photo : STR-V7770
