Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 72 —
DIGITAL DISPLAY
R1275 1-216-025-91 RES,CHIP 100 5% 1/10W
R1276 1-216-025-91 RES,CHIP 100 5% 1/10W
R1277 1-216-025-91 RES,CHIP 100 5% 1/10W
R1278 1-216-025-91 RES,CHIP 100 5% 1/10W
R1279 1-216-025-91 RES,CHIP 100 5% 1/10W
R1280 1-216-025-91 RES,CHIP 100 5% 1/10W
R1281 1-216-295-91 SHORT 0
R1283 1-216-295-91 SHORT 0
R1301 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1302 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1303 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1304 1-216-025-91 RES,CHIP 100 5% 1/10W
R1305 1-216-025-91 RES,CHIP 100 5% 1/10W
R1306 1-216-041-00 METAL CHIP 470 5% 1/10W
R1307 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1308 1-216-065-91 METAL CHIP 4.7K 5% 1/10W
R1309 1-216-025-91 RES,CHIP 100 5% 1/10W
R1310 1-216-121-91 RES,CHIP 1M 5% 1/10W
R1311 1-216-065-91 METAL CHIP 4.7K 5% 1/10W
R1313 1-216-065-91 METAL CHIP 4.7K 5% 1/10W
R1314 1-216-295-91 SHORT 0
R1315 1-216-295-91 SHORT 0
R1316 1-216-295-91 SHORT 0
R1317 1-216-295-91 SHORT 0
R1318 1-216-295-91 SHORT 0
! R1319 1-215-884-11 METAL OXIDE 47 5% 2W F
R1320 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1321 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1322 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1323 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1324 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1325 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1326 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1327 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1328 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1329 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1330 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R1401 1-216-025-91 RES,CHIP 100 5% 1/10W
R1402 1-216-025-91 RES,CHIP 100 5% 1/10W
R1403 1-216-025-91 RES,CHIP 100 5% 1/10W
R1404 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1405 1-216-025-91 RES,CHIP 100 5% 1/10W
R1406 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1407 1-216-295-91 SHORT 0
R1408 1-216-025-91 RES,CHIP 100 5% 1/10W
R1409 1-216-025-91 RES,CHIP 100 5% 1/10W
R1410 1-216-295-91 SHORT 0
< VIBRATOR >
X1101 1-567-970-11 VIBRATOR, CRYSTAL 24.576MHz
X1201 1-577-082-11 VIBRATOR, CERAMIC 4MHz
X1301 1-767-949-21 VIBRATOR, CERAMIC 49.152MHz
************************************************************
* A-4414-064-A DISPLAY BOARD, COMPLETE (US,CND)
********************************
* A-4414-082-A DISPLAY BOARD, COMPLETE (E,EA,PX)
******************************
* A-4414-087-A DISPLAY BOARD, COMPLETE (MY,SP)
*******************************
* A-4414-130-A DISPLAY BOARD, COMPLETE (CH)
****************************
(including L.B BOARD)
* 4-921-941-01 CUSHION (FL)
* 4-990-797-01 HOLDER (FL)
< CAPACITOR >
C101 1-104-664-11 ELECT 47uF 20% 16V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-104-905-11 CAPACITOR 0.22F 5.5V
C106 1-164-159-11 CERAMIC 0.1uF 50V
C107 1-164-159-11 CERAMIC 0.1uF 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-164-159-11 CERAMIC 0.1uF 50V
C111 1-164-159-11 CERAMIC 0.1uF 50V
C112 1-164-159-11 CERAMIC 0.1uF 50V
C113 1-164-159-11 CERAMIC 0.1uF 50V
C117 1-164-159-11 CERAMIC 0.1uF 50V
C118 1-164-159-11 CERAMIC 0.1uF 50V
C119 1-104-664-11 ELECT 47uF 20% 16V
C120 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-104-664-11 ELECT 47uF 20% 16V
C122 1-164-159-11 CERAMIC 0.1uF 50V
C123 1-164-159-11 CERAMIC 0.1uF 50V
C124 1-162-294-31 CERAMIC 1000PF 10% 50V
C180 1-164-159-11 CERAMIC 0.1uF 50V
C181 1-136-177-00 CERAMIC 1uF 5% 50V
C182 1-164-159-11 CERAMIC 0.1uF 50V
C183 1-126-916-11 ELECT 1000uF 20% 6.3V
C184 1-126-964-11 ELECT 10uF 20% 50V
C185 1-162-306-11 CERAMIC 0.01uF 20% 16V
C186 1-162-306-11 CERAMIC 0.01uF 20% 16V
CC20 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP105 1-564-510-11 PLUG, CONNECTOR 7P
CNP106 1-784-919-11 CONNECTOR, PC BOARD (PLUG) 5P
CNP113 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNP114 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNP115 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNP116 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNS103 1-784-776-11 CONNECTOR, FFC 15P (US,CND)
CNS103 1-784-772-11 CONNECTOR, FFC 11P (E,EA,MY,SP,CH)
CNS104 1-784-743-11 CONNECTOR, FFC 21P
CNS105 1-564-510-11 PLUG, CONNECTOR 7P (E,EA)
CNS107 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< DIODE >
D101 8-719-313-45 DIODE SEL6810A-TH10
D102 8-719-024-99 DIODE 11ES2-NTA2B
D103 8-719-911-19 DIODE 1SS119
D104 8-719-046-39 DIODE SEL5821A-TH15
D105 8-719-046-39 DIODE SEL5821A-TH15
D106 8-719-046-39 DIODE SEL5821A-TH15
D108 8-719-046-39 DIODE SEL5821A-TH15
D119 8-719-046-39 DIODE SEL5821A-TH15
D122 8-719-046-39 DIODE SEL5821A-TH15
D180 8-719-911-19 DIODE 1SS119
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
