Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 73 —
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
D181 8-719-911-19 DIODE 1SS119
D182 8-719-911-19 DIODE 1SS119
D183 8-719-911-19 DIODE 1SS119
D184 8-719-059-14 DIODE SID313BP-TP19
D185 8-719-059-14 DIODE SID313BP-TP19
D186 8-719-059-14 DIODE SID313BP-TP19
< FILTER >
FL101 1-517-781-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC101 8-759-459-83 IC NJL55H400A (REMOTE SENSOR
IC102 8-759-535-50 IC MB90553PF-G-121-BND
IC103 8-759-962-08 IC BA6208
IC104 8-759-463-11 IC MSC1162AGS-BK
IC105 8-759-389-51 IC MSC1164GS-KR1
IC180 8-759-927-72 IC TL1591CP
IC181 8-759-545-07 IC TMP87C447U-4A06
< COIL >
L101 1-410-509-11 INDUCTOR 10uH
L150 1-408-080-00 INDUCTOR 100uH
< TRANSISTOR >
Q101 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q102 8-729-900-36 TRANSISTOR DTC124ES
Q103 8-729-900-36 TRANSISTOR DTC124ES
Q104 8-729-900-36 TRANSISTOR DTC124ES
Q105 8-729-900-36 TRANSISTOR DTC124ES
Q106 8-729-900-36 TRANSISTOR DTC124ES
Q107 8-729-900-36 TRANSISTOR DTC124ES
Q108 8-729-900-36 TRANSISTOR DTC124ES
Q109 8-729-900-36 TRANSISTOR DTC124ES
Q110 8-729-900-36 TRANSISTOR DTC124ES
Q111 8-729-900-36 TRANSISTOR DTC124ES
Q112 8-729-900-36 TRANSISTOR DTC124ES
Q113 8-729-900-36 TRANSISTOR DTC124ES
Q114 8-729-900-36 TRANSISTOR DTC124ES
Q115 8-729-900-36 TRANSISTOR DTC124ES
Q116 8-729-900-36 TRANSISTOR DTC124ES
Q117 8-729-900-36 TRANSISTOR DTC124ES
Q118 8-729-900-36 TRANSISTOR DTC124ES
Q119 8-729-900-36 TRANSISTOR DTC124ES
Q120 8-729-900-36 TRANSISTOR DTC124ES
Q122 8-729-900-36 TRANSISTOR DTC124ES
Q180 8-729-620-05 TRANSISTOR 2SC2603-EF
Q181 8-729-900-36 TRANSISTOR DTC124ES
Q182 8-729-620-05 TRANSISTOR 2SC2603-EF
Q183 8-729-801-93 TRANSISTOR 2SD1387
Q184 8-729-801-93 TRANSISTOR 2SD1387
< RESISTOR >
R101 1-249-411-11 CARBON 330 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
R103 1-249-437-11 CARBON 47K 5% 1/4W
R104 1-247-772-00 CARBON 3.6 5% 1/4W
R105 1-249-393-11 CARBON 10 5% 1/4W F
R106 1-249-437-11 CARBON 47K 5% 1/4W
R107 1-249-433-11 CARBON 22K 5% 1/4W
R110 1-249-419-11 CARBON 1.5K 5% 1/4W F
R111 1-247-807-31 CARBON 100 5% 1/4W
R112 1-247-807-31 CARBON 100 5% 1/4W
R113 1-247-807-31 CARBON 100 5% 1/4W
R114 1-247-807-31 CARBON 100 5% 1/4W
! R115 1-249-385-11 CARBON 2.2 5% 1/6W F
R116 1-249-429-11 CARBON 10K 5% 1/4W
R117 1-249-433-11 CARBON 22K 5% 1/4W
R118 1-249-433-11 CARBON 22K 5% 1/4W
R119 1-249-417-11 CARBON 1K 5% 1/4W F
R120 1-249-417-11 CARBON 1K 5% 1/4W F
R121 1-249-417-11 CARBON 1K 5% 1/4W F
R122 1-249-429-11 CARBON 10K 5% 1/4W
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R124 1-249-411-11 CARBON 330 5% 1/4W
R125 1-249-425-11 CARBON 4.7K 5% 1/4W F
R126 1-249-425-11 CARBON 4.7K 5% 1/4W F
R127 1-249-425-11 CARBON 4.7K 5% 1/4W F
R128 1-249-425-11 CARBON 4.7K 5% 1/4W F
R129 1-249-417-11 CARBON 1K 5% 1/4W F
R130 1-249-425-11 CARBON 4.7K 5% 1/4W F
R131 1-249-425-11 CARBON 4.7K 5% 1/4W F
R132 1-249-425-11 CARBON 4.7K 5% 1/4W F
R133 1-249-414-11 CARBON 560 5% 1/4W F
R134 1-249-411-11 CARBON 330 5% 1/4W
R135 1-249-411-11 CARBON 330 5% 1/4W
! R161 1-249-385-11 CARBON 2.2 5% 1/6W F
R162 1-249-421-11 CARBON 2.2K 5% 1/4W F
R163 1-249-421-11 CARBON 2.2K 5% 1/4W F
R164 1-249-411-11 CARBON 330 5% 1/4W
R165 1-249-429-11 CARBON 10K 5% 1/4W
R166 1-249-411-11 CARBON 330 5% 1/4W
R167 1-249-413-11 CARBON 470 5% 1/4W F
R168 1-249-415-11 CARBON 680 5% 1/4W F
R169 1-249-417-11 CARBON 1K 5% 1/4W F
R170 1-249-419-11 CARBON 1.5K 5% 1/4W F
R171 1-249-425-11 CARBON 4.7K 5% 1/4W F
R172 1-249-421-11 CARBON 2.2K 5% 1/4W F
R175 1-249-415-11 CARBON 680 5% 1/4W F
R176 1-249-413-11 CARBON 470 5% 1/4W F
R177 1-249-411-11 CARBON 330 5% 1/4W
R178 1-249-417-11 CARBON 1K 5% 1/4W F
R179 1-249-411-11 CARBON 330 5% 1/4W
R180 1-249-393-11 CARBON 10 5% 1/4W F
R181 1-249-429-11 CARBON 10K 5% 1/4W
R182 1-249-425-11 CARBON 4.7K 5% 1/4W F
R183 1-249-429-11 CARBON 10K 5% 1/4W
R184 1-249-429-11 CARBON 10K 5% 1/4W
R185 1-249-425-11 CARBON 4.7K 5% 1/4W F
R186 1-249-429-11 CARBON 10K 5% 1/4W
R187 1-249-383-11 CARBON 1.5 5% 1/6W F
R188 1-249-429-11 CARBON 10K 5% 1/4W
R189 1-247-772-00 CARBON 3.6 5% 1/4W
DISPLAY
To Next Page
