Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 74 —
R190 1-249-441-11 CARBON 100K 5% 1/4W
R191 1-247-807-31 CARBON 100 5% 1/4W
R192 1-249-383-11 CARBON 1.5 5% 1/6W F
R193 1-247-807-31 CARBON 100 5% 1/4W
R194 1-247-807-31 CARBON 100 5% 1/4W
R195 1-247-807-31 CARBON 100 5% 1/4W
R196 1-247-807-31 CARBON 100 5% 1/4W
R197 1-249-441-11 CARBON 100K 5% 1/4W
R198 1-249-429-11 CARBON 10K 5% 1/4W
R199 1-249-429-11 CARBON 10K 5% 1/4W
RR10 1-249-425-11 CARBON 4.7K 5% 1/4W F
RR11 1-249-411-11 CARBON 330 5% 1/4W
(E,EA,MY,SP,CH,PX)
RR12 1-249-413-11 CARBON 470 5% 1/4W F
(MY,SP,CH)
RR13 1-249-415-11 CARBON 680 5% 1/4W F
(CH)
RR20 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S102 1-762-750-11 SWITCH, TACTILE (MUTING)
S131 1-762-750-11 SWITCH, TACTILE (POWER)
S132 1-762-750-11 SWITCH, TACTILE (DISP)
S133 1-762-750-11 SWITCH, TACTILE (PRE+)
S135 1-762-750-11 SWITCH, TACTILE (LEFT)
S136 1-762-750-11 SWITCH, TACTILE (UP)
S137 1-762-750-11 SWITCH, TACTILE (RIGHT)
S138 1-762-750-11 SWITCH, TACTILE (FM/AM)
S139 1-762-750-11 SWITCH, TACTILE (FM MODE)
S142 1-762-750-11 SWITCH, TACTILE (MEMORY)
S143 1-762-750-11 SWITCH, TACTILE (SLEEP)
S144 1-762-750-11 SWITCH, TACTILE (TUN+)
S145 1-762-750-11 SWITCH, TACTILE (TUN-)
S146 1-762-750-11 SWITCH, TACTILE (PRE-)
S147 1-762-750-11 SWITCH, TACTILE (DOWN)
< VIBRATOR >
X101 1-577-082-11 VIBRATOR, CERAMIC 4MHz
X180 1-767-938-21 VIBRATOR, CERAMIC 7.28MHz
************************************************************
* 1-670-012-11 F-VIDEO BOARD
*************
< CAPACITOR >
C299 1-164-159-11 CERAMIC 0.1uF 50V
CC14 1-162-282-31 CERAMIC 100PF 10% 50V
CC64 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CNP307 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
< EARTH >
* EB201 1-537-738-21 TERMINAL, EARTH
< JACK >
J299 1-779-798-11 JACK, PIN (BLOCK) (L TYPE) 3P
(VIDEO3 INPUT)
< RESISTOR >
R299 1-247-804-11 CARBON 75 5% 1/4W
R321 1-249-417-11 CARBON 1K 5% 1/4W F
R371 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* 1-670-006-11 H.P BOARD
*********
< JACK >
J701 1-568-519-41 JACK, LARGE TYPE (PHONES)
************************************************************
* A-4414-062-A INPUT BOARD, COMPLETE (US,CND,E,EA,PX)
***********************************
* A-4414-086-A INPUT BOARD, COMPLETE (MY,SP)
*****************************
* A-4414-129-A INPUT BOARD, COMPLETE (CH)
**************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C301 1-126-045-11 ELECT 2.2uF 20% 50V
C303 1-126-101-11 ELECT 100uF 20% 16V
C304 1-125-896-91 MYLAR 0.0091uF 5% 50V
C305 1-136-159-00 FILM 0.033uF 5% 50V
C306 1-126-045-11 ELECT 2.2uF 20% 50V
C307 1-162-282-31 CERAMIC 100PF 10% 50V
C308 1-162-286-31 CERAMIC 220PF 10% 50V
C310 1-162-294-31 CERAMIC 0.001uF 10% 50V
C311 1-126-233-11 ELECT 22uF 20% 50V
C351 1-126-045-11 ELECT 2.2uF 20% 50V
C353 1-126-101-11 ELECT 100uF 20% 16V
C354 1-125-896-91 MYLAR 0.0091uF 5% 50V
C355 1-136-159-00 FILM 0.033uF 5% 50V
C356 1-126-045-11 ELECT 2.2uF 20% 50V
C357 1-162-282-31 CERAMIC 100PF 10% 50V
C358 1-162-286-31 CERAMIC 220PF 10% 50V
C360 1-162-294-31 CERAMIC 0.001uF 10% 50V
C361 1-126-233-11 ELECT 22uF 20% 50V
C388 1-126-052-11 ELECT 100uF 20% 16V
C389 1-126-052-11 ELECT 100uF 20% 16V
C392 1-126-022-11 ELECT 47uF 20% 16V
C393 1-162-294-31 CERAMIC 0.001uF 10% 50V
C394 1-126-022-11 ELECT 47uF 20% 16V
C395 1-162-282-31 CERAMIC 100PF 10% 50V
C401 1-126-233-11 ELECT 22uF 20% 50V
C402 1-126-233-11 ELECT 22uF 20% 50V
C403 1-126-233-11 ELECT 22uF 20% 50V
C404 1-162-199-31 CERAMIC 10PF 5% 50V
C405 1-162-199-31 CERAMIC 10PF 5% 50V
C406 1-162-199-31 CERAMIC 10PF 5% 50V
C407 1-126-233-11 ELECT 22uF 20% 50V
C408 1-126-233-11 ELECT 22uF 20% 50V
C409 1-126-233-11 ELECT 22uF 20% 50V
C416 1-126-233-11 ELECT 22uF 20% 50V
C417 1-126-233-11 ELECT 22uF 20% 50V
C418 1-126-233-11 ELECT 22uF 20% 50V
C419 1-162-282-31 CERAMIC 100PF 10% 50V
C451 1-126-233-11 ELECT 22uF 20% 50V
C452 1-126-233-11 ELECT 22uF 20% 50V
C453 1-126-233-11 ELECT 22uF 20% 50V
DISPLAY F-VIDEO INPUTH.P
