Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 79 —
R256 1-249-429-11 CARBON 10K 5% 1/4W
R257 1-247-804-11 CARBON 75 5% 1/4W
R258 1-247-804-11 CARBON 75 5% 1/4W
R259 1-247-804-11 CARBON 75 5% 1/4W
R260 1-247-804-11 CARBON 75 5% 1/4W
R261 1-247-804-11 CARBON 75 5% 1/4W
R262 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
* A-4414-076-A SP BOARD, COMPLETE (US,CND,E,EA,PX)
********************************
* A-4414-090-A SP BOARD, COMPLETE (MY,SP,CH)
*****************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C624 1-126-059-11 ELECT 10uF 20% 50V
C626 1-136-153-00 FILM 0.01uF 5% 50V
C724 1-126-059-11 ELECT 10uF 20% 50V
C726 1-136-153-00 FILM 0.01uF 5% 50V
C794 1-126-059-11 ELECT 10uF 20% 50V
C795 1-126-941-11 ELECT 470uF 20% 25V
CC41 1-162-290-31 CERAMIC 470PF 10% 50V
CC42 1-162-290-31 CERAMIC 470PF 10% 50V
CC43 1-162-290-31 CERAMIC 470PF 10% 50V
< JACK >
CNJ701 1-774-136-11 CONNECTOR, ROUND TYPE 6P
(WIRELESS REAR SPEAKER)
< CONNECTOR >
CNP601 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP602 1-784-922-11 PIN, CONNECTOR 5P
CNP603 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D543 8-719-911-19 DIODE 1SS119
D605 8-719-911-19 DIODE 1SS119
D606 8-719-911-19 DIODE 1SS119
D607 8-719-911-19 DIODE 1SS119
D649 8-719-911-19 DIODE 1SS119
D705 8-719-911-19 DIODE 1SS119
D706 8-719-911-19 DIODE 1SS119
D749 8-719-911-19 DIODE 1SS119
< IC >
IC702 8-759-605-01 IC M5F78M18L
< JACK >
J501 1-770-157-21 JACK, PIN 2P (WOOFER)
< COIL >
L601 1-420-872-00 COIL, AIR-CORE (US,CND,E,EA,PX)
L601 1-411-906-11 COIL, AIR-CORE (MY,SP,CH)
L701 1-420-872-00 COIL, AIR-CORE (US,CND,E,EA,PX)
L701 1-411-906-11 COIL, AIR-CORE (MY,SP,CH)
L751 1-420-872-00 COIL, AIR-CORE (US,CND,E,EA,PX)
L751 1-411-906-11 COIL, AIR-CORE (MY,SP,CH)
< TRANSISTOR >
Q544 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q609 8-729-281-53 TRANSISTOR 2SC1815-GR
Q610 8-729-900-63 TRANSISTOR DTA124ES
Q611 8-729-900-63 TRANSISTOR DTA124ES
Q645 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q709 8-729-281-53 TRANSISTOR 2SC1815-GR
Q710 8-729-900-63 TRANSISTOR DTA124ES
Q745 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q747 8-729-620-05 TRANSISTOR 2SC2603-EF
Q748 8-729-030-19 TRANSISTOR 2SB1640
< RESISTOR >
R543 1-249-429-11 CARBON 10K 5% 1/4W
R544 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R545 1-249-393-11 CARBON 10 5% 1/4W F
R629 1-247-866-11 CARBON 30K 5% 1/4W
R630 1-249-421-11 CARBON 2.2K 5% 1/4W F
R631 1-249-433-11 CARBON 22K 5% 1/4W
! R634 1-249-389-11 CARBON 4.7 5% 1/4W F
R635 1-249-431-11 CARBON 15K 5% 1/4W
R636 1-249-433-11 CARBON 22K 5% 1/4W
R647 1-249-429-11 CARBON 10K 5% 1/4W
R648 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R649 1-249-393-11 CARBON 10 5% 1/4W F
R729 1-247-866-11 CARBON 30K 5% 1/4W
R730 1-249-421-11 CARBON 2.2K 5% 1/4W F
R731 1-249-433-11 CARBON 22K 5% 1/4W
! R734 1-249-389-11 CARBON 4.7 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
R737 1-249-429-11 CARBON 10K 5% 1/4W
R738 1-247-887-00 CARBON 220K 5% 1/4W
R743 1-249-425-11 CARBON 4.7K 5% 1/4W F
R744 1-249-425-11 CARBON 4.7K 5% 1/4W F
R745 1-249-421-11 CARBON 2.2K 5% 1/4W F
R746 1-249-421-11 CARBON 2.2K 5% 1/4W F
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R749 1-249-393-11 CARBON 10 5% 1/4W F
! R784 1-249-389-11 CARBON 4.7 5% 1/4W F
R787 1-249-429-11 CARBON 10K 5% 1/4W
R788 1-247-887-00 CARBON 220K 5% 1/4W
< RELAY >
RY503 1-515-793-11 RELAY
RY601 1-515-920-11 RELAY (24V)
RY701 1-515-920-11 RELAY (24V)
< SWITCH >
S501 1-692-196-11 SWITCH, SLIDE (IMPEDANCE SELECTOR)
< TERMINAL >
TM701 1-694-431-21 TERMINAL BOARD (SPEAKERS)
************************************************************
SPS-VIDEO
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
