Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 80 —
VIDEO
* 1-670-010-11 SP SW BOARD
***********
< DIODE >
D120 8-719-911-19 DIODE 1SS119
D121 8-719-911-19 DIODE 1SS119
< RESISTOR >
R173 1-249-421-11 CARBON 2.2K 5% 1/4W F
R174 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S134 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
S140 1-762-750-11 SWITCH, TACTILE (SET UP)
S141 1-762-750-11 SWITCH, TACTILE (CURSOR)
************************************************************
* A-4414-065-A SW BOARD, COMPLETE
******************
< CAPACITOR >
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-164-159-11 CERAMIC 0.1uF 50V
C116 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNS113 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
CNS114 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
CNS115 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
CNS116 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< DIODE >
D109 8-719-046-39 DIODE SEL5821A-TH15
D110 8-719-046-39 DIODE SEL5821A-TH15
D111 8-719-046-39 DIODE SEL5821A-TH15
D112 8-719-046-39 DIODE SEL5821A-TH15
D113 8-719-046-39 DIODE SEL5821A-TH15
D114 8-719-046-39 DIODE SEL5821A-TH15
D115 8-719-046-39 DIODE SEL5821A-TH15
D116 8-719-046-39 DIODE SEL5821A-TH15
D117 8-719-046-39 DIODE SEL5821A-TH15
D118 8-719-046-39 DIODE SEL5821A-TH15
< RESISTOR >
R136 1-249-413-11 CARBON 470 5% 1/4W F
R137 1-249-411-11 CARBON 330 5% 1/4W
R138 1-249-411-11 CARBON 330 5% 1/4W
R139 1-249-411-11 CARBON 330 5% 1/4W
R140 1-249-415-11 CARBON 680 5% 1/4W F
R141 1-249-413-11 CARBON 470 5% 1/4W F
R142 1-249-413-11 CARBON 470 5% 1/4W F
R143 1-249-413-11 CARBON 470 5% 1/4W F
R144 1-249-417-11 CARBON 1K 5% 1/4W F
R145 1-249-415-11 CARBON 680 5% 1/4W F
R146 1-249-415-11 CARBON 680 5% 1/4W F
R147 1-249-415-11 CARBON 680 5% 1/4W F
R148 1-249-419-11 CARBON 1.5K 5% 1/4W F
R149 1-249-417-11 CARBON 1K 5% 1/4W F
R150 1-249-417-11 CARBON 1K 5% 1/4W F
R151 1-249-417-11 CARBON 1K 5% 1/4W F
R152 1-249-421-11 CARBON 2.2K 5% 1/4W F
R153 1-249-419-11 CARBON 1.5K 5% 1/4W F
R154 1-249-419-11 CARBON 1.5K 5% 1/4W F
R155 1-249-419-11 CARBON 1.5K 5% 1/4W F
R156 1-249-425-11 CARBON 4.7K 5% 1/4W F
R157 1-249-421-11 CARBON 2.2K 5% 1/4W F
R158 1-249-421-11 CARBON 2.2K 5% 1/4W F
R159 1-249-425-11 CARBON 4.7K 5% 1/4W F
R160 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S103 1-762-750-11 SWITCH, TACTILE (BOOST)
S104 1-762-750-11 SWITCH, TACTILE (VIDEO 3)
S105 1-762-750-11 SWITCH, TACTILE (SHIFT)
S106 1-762-750-11 SWITCH, TACTILE (DIRECT)
S107 1-762-750-11 SWITCH, TACTILE (EQ ON/OFF)
S108 1-762-750-11 SWITCH, TACTILE (DVD/LD)
S109 1-762-750-11 SWITCH, TACTILE (6)
S110 1-762-750-11 SWITCH, TACTILE (1)
S111 1-762-750-11 SWITCH, TACTILE (INPUT)
S112 1-762-750-11 SWITCH, TACTILE (TV/DBS)
S113 1-762-750-11 SWITCH, TACTILE (7)
S114 1-762-750-11 SWITCH, TACTILE (2)
S115 1-762-750-11 SWITCH, TACTILE (GENRE)
S116 1-762-750-11 SWITCH, TACTILE (PHONO)
S117 1-762-750-11 SWITCH, TACTILE (8)
S118 1-762-750-11 SWITCH, TACTILE (3)
S119 1-762-750-11 SWITCH, TACTILE (SF MODE)
S120 1-762-750-11 SWITCH, TACTILE (TUNER)
S121 1-762-750-11 SWITCH, TACTILE (9)
S122 1-762-750-11 SWITCH, TACTILE (4)
S123 1-762-750-11 SWITCH, TACTILE (SF ON/OFF)
S124 1-762-750-11 SWITCH, TACTILE (CD)
S125 1-762-750-11 SWITCH, TACTILE (0)
S126 1-762-750-11 SWITCH, TACTILE (5)
S127 1-762-750-11 SWITCH, TACTILE (TAPE)
S128 1-762-750-11 SWITCH, TACTILE (VIDEO 1)
S129 1-762-750-11 SWITCH, TACTILE (MD/DAT)
S130 1-762-750-11 SWITCH, TACTILE (VIDEO 2)
************************************************************
* 1-670-000-11 TUNER BOARD
***********
< CONNECTOR >
CNS304 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CNS305 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
************************************************************
* 1-670-003-11 VIDEO BOARD
***********
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-162-215-31 CERAMIC 47PF 5% 50V
SW TUNERSP SW
