Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 81 —
C206 1-162-215-31 CERAMIC 47PF 5% 50V
C207 1-162-215-31 CERAMIC 47PF 5% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-164-159-11 CERAMIC 0.1uF 50V
C210 1-164-159-11 CERAMIC 0.1uF 50V
C211 1-164-159-11 CERAMIC 0.1uF 50V
C212 1-164-159-11 CERAMIC 0.1uF 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
CNS210 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CNS211 1-784-737-11 CONNECTOR, FFC 15P (US,CND)
CNS211 1-784-733-11 CONNECTOR, FFC 11P (E,EA,MY,SP,CH,PX)
CNS212 1-784-731-11 CONNECTOR, FFC 9P (MY,SP,CH)
CNS215 1-784-729-11 CONNECTOR, FFC 7P (US,CND)
< DIODE >
D201 8-719-911-19 DIODE 1SS119
D202 8-719-911-19 DIODE 1SS119
< IC >
IC201 8-759-529-20 IC NJM2296D
IC202 8-759-701-65 IC NJM79M05FA
< JACK >
J201 1-766-399-11 JACK, PIN 3P (MONITOR/VIDEO 1)
J202 1-766-400-11 JACK, PIN 2P (VIDEO 2)
J203 1-766-400-11 JACK, PIN 2P (TV/DBS,DVD/LD)(DE925)
(TV/LD,DVD)(V919)
J204 1-563-330-11 JACK (S-LINK)
< RESISTOR >
R201 1-247-804-11 CARBON 75 5% 1/4W
R202 1-247-804-11 CARBON 75 5% 1/4W
R203 1-247-804-11 CARBON 75 5% 1/4W
R204 1-247-804-11 CARBON 75 5% 1/4W
R205 1-247-804-11 CARBON 75 5% 1/4W
R206 1-247-804-11 CARBON 75 5% 1/4W
R207 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
* A-4414-066-A VOLUME BOARD, COMPLETE
**********************
(including BALANCE BOARD)
< CAPACITOR >
C410 1-126-233-11 ELECT 22uF 20% 50V
C411 1-126-233-11 ELECT 22uF 20% 50V
C412 1-126-233-11 ELECT 22uF 20% 50V
C413 1-162-199-31 CERAMIC 10PF 5% 50V
C414 1-162-199-31 CERAMIC 10PF 5% 50V
C415 1-162-199-31 CERAMIC 10PF 5% 50V
C421 1-162-286-31 CERAMIC 220PF 10% 50V
C422 1-162-286-31 CERAMIC 220PF 10% 50V
C423 1-162-286-31 CERAMIC 220PF 10% 50V
C460 1-126-233-11 ELECT 22uF 20% 50V
C461 1-126-233-11 ELECT 22uF 20% 50V
C462 1-126-233-11 ELECT 22uF 20% 50V
C463 1-162-199-31 CERAMIC 10PF 5% 50V
C464 1-162-199-31 CERAMIC 10PF 5% 50V
C465 1-162-199-31 CERAMIC 10PF 5% 50V
C471 1-162-286-31 CERAMIC 220PF 10% 50V
C472 1-162-286-31 CERAMIC 220PF 10% 50V
C473 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CNP101 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
* CNS402 1-564-726-11 PIN, CONNECTOR (SMALL TYPE)10P
< IC >
IC408 8-759-634-50 IC M5218AL
IC409 8-759-634-50 IC M5218AL
IC410 8-759-634-50 IC M5218AL
< RESISTOR >
R413 1-249-437-11 CARBON 47K 5% 1/4W
R414 1-249-437-11 CARBON 47K 5% 1/4W
R415 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-429-11 CARBON 10K 5% 1/4W
R417 1-247-843-11 CARBON 3.3K 5% 1/4W
R418 1-249-437-11 CARBON 47K 5% 1/4W
R419 1-249-437-11 CARBON 47K 5% 1/4W
R420 1-249-437-11 CARBON 47K 5% 1/4W
R421 1-249-437-11 CARBON 47K 5% 1/4W
R463 1-249-437-11 CARBON 47K 5% 1/4W
R464 1-249-437-11 CARBON 47K 5% 1/4W
R465 1-249-437-11 CARBON 47K 5% 1/4W
R466 1-249-429-11 CARBON 10K 5% 1/4W
R467 1-247-843-11 CARBON 3.3K 5% 1/4W
R468 1-247-843-11 CARBON 3.3K 5% 1/4W
R469 1-249-437-11 CARBON 47K 5% 1/4W
R470 1-249-437-11 CARBON 47K 5% 1/4W
R471 1-249-437-11 CARBON 47K 5% 1/4W
RR108 1-249-411-11 CARBON 330 5% 1/4W
< VARIABLE RESISTOR >
RV401 1-225-445-11 RES, VAR, CARBON 100KX6
(MASTER VOLUME)
RV402 1-238-965-21 RES, VAR, CARBON 100K/100K (BALANCE)
************************************************************
MISCELLANEOUS
**************
12 1-773-161-11 WIRE (FLAT TYPE) (21 CORE)
13 1-769-959-11 WIRE (FLAT TYPE) (11 CORE)
13 1-773-025-11 WIRE (FLAT TYPE) (15 CORE)(US,CND)
64 1-693-407-11 TUNER (US,CND)
64 1-693-409-11 TUNER (E,EA,MY,SP,CH,PX)
66 1-773-285-11 WIRE (FLAT TYPE) (29 CORE)
! 73 1-769-743-11 CORD, POWER (US,CND)
! 73 1-769-744-11 CORD, POWER (E,EA,MY,SP,PX)
! 73 1-782-464-21 CORD, POWER (CH)
! 74 1-569-008-31 ADAPTOR, CONVERSION (E,EA,PX)
75 1-769-904-11 WIRE (FLAT TYPE) (9 CORE) (MY,SP,CH)
76 1-769-876-11 WIRE (FLAT TYPE) (7 CORE)
! CNJ901 1-526-794-11 OUTLET, AC (MY,SP)
! T901 1-431-891-11 TRANSFORMER, POWER (US)
! T901 1-431-892-11 TRANSFORMER, POWER (CND)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VOLUMEVIDEO
