Front speaker (Left)

Front speaker (Right)

Center speaker

Surround speaker (Left)

Surround speaker (Right)

Subwoofer

Zone 2 speaker (Left)

Zone 2 speaker (Right)

Hint

As the subwoofer does not emit highly directional signals, you can place it wherever you

want.

How to connect speaker cables

Connect speaker cables as illustrated below.
