NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 38 —
SECTION 7
ELECTRICAL PARTS LIST
• Abbreviations
HK : Hong Kong
SP : Singapore
CONTROL
CONNECTION
* A-2007-825-A CONNECTION BOARD, COMPLETE
***************************
< RESISTOR >
R221 1-247-855-11 CARBON 10K 5% 1/4W
R225 1-247-839-11 CARBON 2.2K 5% 1/4W
R226 1-247-843-11 CARBON 3.3K 5% 1/4W
R227 1-247-863-11 CARBON 22K 5% 1/4W
R228 1-247-871-11 CARBON 47K 5% 1/4W
< SWITCH >
S7 1-572-647-11 SWITCH, KEY BOARD (POWER)
S11 1-692-505-11 SWITCH, SLIDE (DIRECTION)
S12 1-692-505-11 SWITCH, SLIDE (DOLBY NR)
************************************************************
* A-2007-819-A CONTROL BOARD, COMPLETE
************************
< CAPACITOR >
C68 1-162-282-31 CERAMIC 100PF 10% 50V
C69 1-137-372-11 FILM 0.022uF 5% 50V
C70 1-162-217-31 CERAMIC 56PF 5% 50V
C71 1-126-961-11 ELECT 2.2uF 20% 50V
C73 1-126-960-11 ELECT 1uF 20% 50V
C74 1-126-916-11 ELECT 1000uF 20% 6.3V
C75 1-161-494-00 CERAMIC 0.022uF 25V
C76 1-126-964-11 ELECT 10uF 20% 50V
C77 1-164-159-11 CERAMIC 0.1uF 50V
C78 1-162-306-11 CERAMIC 0.01uF 20% 16V
C79 1-162-306-11 CERAMIC 0.01uF 20% 16V
C81 1-126-935-11 ELECT 470uF 20% 16V
C82 1-126-934-11 ELECT 220uF 20% 16V
C83 1-162-282-31 CERAMIC 100PF 10% 50V
C70A 1-126-964-11 ELECT 10uF 20% 50V
C74A 1-164-159-11 CERAMIC 0.1uF 50V
C76A 1-126-963-11 ELECT 4.7uF 20% 50V
C76B 1-104-664-11 ELECT 47uF 20% 16V
C77A 1-164-159-11 CERAMIC 0.1uF 50V
< FILTER >
CF01 1-579-125-11 VIBRATOR, CERAMIC 8MHz
< CONNECTOR >
* CN05 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN07 1-785-785-11 SOCKET, CONNECTOR 10P
* CN08 1-564-715-11 PIN, CONNECTOR (SMALL TYPE)13P
CN09 1-568-802-11 SOCKET, CONNECTOR 19P
CN12 1-785-779-11 SOCKET, CONNECTOR 13P
CN12A 1-785-780-11 HEADER, PIN 13P
* CN14 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D02 8-719-911-19 DIODE 1SS119
D03 8-719-911-19 DIODE 1SS119
D04 8-719-911-19 DIODE 1SS119
D13 8-719-109-97 DIODE RD6.8ES-B2
D14 8-719-109-85 DIODE RD5.1ES-B2
D15 8-719-911-19 DIODE 1SS119
D16 8-719-109-85 DIODE RD5.1ES-B2
D19 8-719-055-76 DIODE 1N4148
D20 8-719-911-19 DIODE 1SS119
D28 8-719-200-02 DIODE 10E2
< IC >
IC05 8-759-575-34 IC TMP87CH48DF-4B67
IC06 8-759-822-09 IC LB1641
IC07 8-759-165-85 IC PST600H-T
IC08 8-759-710-59 IC NJM4580D-D
< TRANSISTOR >
Q19 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q21 8-729-900-63 TRANSISTOR DTA124ES
Q22 8-729-900-63 TRANSISTOR DTA124ES
Q23 8-729-900-63 TRANSISTOR DTA124ES
Q24 8-729-993-43 TRANSISTOR 2SA934R
Q25 8-729-993-43 TRANSISTOR 2SA934R
Q26 8-729-029-86 TRANSISTOR DTC124ESA
Q27 8-729-029-86 TRANSISTOR DTC124ESA
Q29 8-729-900-63 TRANSISTOR DTA124ES
Q30 8-729-900-63 TRANSISTOR DTA124ES
Q31 8-729-900-63 TRANSISTOR DTA124ES
Q32 8-729-900-63 TRANSISTOR DTA124ES
Q33 8-729-900-63 TRANSISTOR DTA124ES
Q34 8-729-900-63 TRANSISTOR DTA124ES
Q35 8-729-900-63 TRANSISTOR DTA124ES
Q36 8-729-900-63 TRANSISTOR DTA124ES
Q38 8-729-900-63 TRANSISTOR DTA124ES
