Sony TC-SD1 - Page 27

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 39 —
CONTROL DOLBY
< RESISTOR >
R76 1-249-437-11 CARBON 47K 5% 1/4W
R77 1-249-427-11 CARBON 6.8K 5% 1/4W F
R78 1-247-843-11 CARBON 3.3K 5% 1/4W
R79 1-247-879-11 CARBON 100K 5% 1/4W
R80 1-247-879-11 CARBON 100K 5% 1/4W
R81 1-247-855-11 CARBON 10K 5% 1/4W
R82 1-249-417-11 CARBON 1K 5% 1/4W F
R83 1-249-432-11 CARBON 18K 5% 1/4W
R84 1-249-436-11 CARBON 39K 5% 1/4W
R85 1-247-879-11 CARBON 100K 5% 1/4W
R86 1-249-417-11 CARBON 1K 5% 1/4W F
R87 1-249-413-11 CARBON 470 5% 1/4W F
R88 1-247-855-11 CARBON 10K 5% 1/4W
R89 1-247-855-11 CARBON 10K 5% 1/4W
R90 1-249-417-11 CARBON 1K 5% 1/4W F
R91 1-249-417-11 CARBON 1K 5% 1/4W F
R96 1-247-855-11 CARBON 10K 5% 1/4W
R97 1-249-417-11 CARBON 1K 5% 1/4W F
R98 1-247-855-11 CARBON 10K 5% 1/4W
R99 1-249-417-11 CARBON 1K 5% 1/4W F
R100 1-247-807-11 CARBON 100 5% 1/4W
R101 1-247-855-11 CARBON 10K 5% 1/4W
R102 1-247-847-11 CARBON 4.7K 5% 1/4W
R103 1-247-807-11 CARBON 100 5% 1/4W
R104 1-249-427-11 CARBON 6.8K 5% 1/4W F
R105 1-249-427-11 CARBON 6.8K 5% 1/4W F
R107 1-249-398-11 CARBON 27 5% 1/4W F
R109 1-247-867-11 CARBON 33K 5% 1/4W
R110 1-247-807-11 CARBON 100 5% 1/4W
R111 1-247-879-11 CARBON 100K 5% 1/4W
R112 1-249-430-11 CARBON 12K 5% 1/4W
R113 1-249-440-11 CARBON 82K 5% 1/4W
R114 1-249-417-11 CARBON 1K 5% 1/4W F
R116 1-249-427-11 CARBON 6.8K 5% 1/4W F
R117 1-249-412-11 CARBON 390 5% 1/4W F
R20A 1-247-855-11 CARBON 10K 5% 1/4W
R200 1-249-412-11 CARBON 390 5% 1/4W F
R201 1-249-412-11 CARBON 390 5% 1/4W F
R202 1-249-412-11 CARBON 390 5% 1/4W F
R203 1-249-412-11 CARBON 390 5% 1/4W F
R204 1-249-409-11 CARBON 220 5% 1/4W F
R205 1-249-409-11 CARBON 220 5% 1/4W F
R206 1-249-412-11 CARBON 390 5% 1/4W F
R207 1-249-412-11 CARBON 390 5% 1/4W F
R208 1-249-412-11 CARBON 390 5% 1/4W F
R209 1-249-412-11 CARBON 390 5% 1/4W F
R210 1-249-412-11 CARBON 390 5% 1/4W F
R211 1-249-412-11 CARBON 390 5% 1/4W F
R212 1-249-412-11 CARBON 390 5% 1/4W F
R214 1-249-412-11 CARBON 390 5% 1/4W F
R404 1-249-437-11 CARBON 47K 5% 1/4W
R102A 1-247-855-11 CARBON 10K 5% 1/4W
< CIRCUIT BLOCK >
RA01 1-234-267-11 CIRCUIT BLOCK, COMPOSITION (10K × 11)
************************************************************
* A-2007-818-A DOLBY BOARD, COMPLETE
**********************
< CAPACITOR >
C01 1-162-292-31 CERAMIC 680PF 10% 50V
C02 1-162-292-31 CERAMIC 680PF 10% 50V
C03 1-162-282-31 CERAMIC 100PF 10% 50V
C04 1-162-282-31 CERAMIC 100PF 10% 50V
C05 1-137-372-11 FILM 0.022uF 5% 50V
C06 1-137-372-11 FILM 0.022uF 5% 50V
C07 1-104-664-11 ELECT 47uF 20% 25V
C08 1-104-664-11 ELECT 47uF 20% 25V
C09 1-107-714-11 ELECT 10uF 20% 16V
C10 1-107-714-11 ELECT 10uF 20% 16V
C11 1-126-925-11 ELECT 470uF 20% 10V
C12 1-126-925-11 ELECT 470uF 20% 10V
C13 1-137-372-11 FILM 0.022uF 5% 50V
C14 1-137-372-11 FILM 0.022uF 5% 50V
C15 1-126-964-11 ELECT 10uF 20% 50V
C16 1-107-714-11 ELECT 10uF 20% 16V
C17 1-162-288-31 CERAMIC 330PF 10% 50V
C18 1-162-288-31 CERAMIC 330PF 10% 50V
C19 1-107-609-11 CERAMIC 75PF 5% 500V
C20 1-107-609-11 CERAMIC 75PF 5% 500V
C21 1-107-610-11 CERAMIC 82PF 5% 500V
C22 1-107-610-11 CERAMIC 82PF 5% 500V
C23 1-136-562-11 FILM 0.0082uF 5% 630V
C24 1-126-961-11 ELECT 2.2uF 20% 50V
C25 1-137-436-11 FILM 0.0039uF 5% 50V
C26 1-137-436-11 FILM 0.0039uF 5% 50V
C27 1-137-370-11 FILM 0.01uF 5% 50V
C28 1-126-960-11 ELECT 1uF 20% 50V
C29 1-104-665-11 ELECT 100uF 20% 25V
C30 1-126-961-11 ELECT 2.2uF 20% 50V
C33 1-126-963-11 ELECT 4.7uF 20% 50V
C34 1-126-963-11 ELECT 4.7uF 20% 50V
C35 1-162-282-31 CERAMIC 100PF 10% 50V
C36 1-162-282-31 CERAMIC 100PF 10% 50V
C37 1-126-964-11 ELECT 10uF 20% 50V
C38 1-126-964-11 ELECT 10uF 20% 50V
C39 1-136-165-00 FILM 0.1uF 5% 50V
C40 1-136-165-00 FILM 0.1uF 5% 50V
C41 1-136-163-00 FILM 0.068uF 5% 50V
C42 1-136-163-00 FILM 0.068uF 5% 50V
C43 1-126-964-11 ELECT 10uF 20% 50V
C44 1-126-964-11 ELECT 10uF 20% 50V
C45 1-104-665-11 ELECT 100uF 20% 10V
C46 1-104-665-11 ELECT 100uF 20% 10V
C47 1-126-960-11 ELECT 1uF 20% 50V
C60 1-126-960-11 ELECT 1uF 20% 50V
C61 1-126-960-11 ELECT 1uF 20% 50V
C62 1-126-961-11 ELECT 2.2uF 20% 50V
C63 1-126-961-11 ELECT 2.2uF 20% 50V
C64 1-162-282-31 CERAMIC 100PF 10% 50V
C65 1-162-282-31 CERAMIC 100PF 10% 50V
C66 1-162-306-11 CERAMIC 0.01uF 20% 16V
C67 1-162-306-11 CERAMIC 0.01uF 20% 16V
C400 1-126-960-11 ELECT 1uF 20% 50V
C401 1-126-960-11 ELECT 1uF 20% 50V
