Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 40 —
DOLBY
< CONNECTOR >
* CN01 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN04 1-785-778-11 SOCKET, CONNECTOR 8P
< DIODE >
D01 8-719-911-19 DIODE 1SS119
D05 8-719-911-19 DIODE 1SS119
D06 8-719-911-19 DIODE 1SS119
< IC >
IC01 8-759-112-93 IC UPC4570HA-1
IC02 8-752-060-46 IC CXA1561S
IC03 8-752-070-69 IC CXA1598S
< COIL >
L01 1-414-223-11 INDUCTOR 470uH
L02 1-414-223-11 INDUCTOR 470uH
L03 1-410-780-11 INDUCTOR 27mH
L04 1-410-780-11 INDUCTOR 27mH
L07 1-429-316-11 TRANSFORMER, BIAS OSCILLATION (BIAS)
< FILTER >
LPF05 1-236-087-11 FILTER, LOW PASS
LPF06 1-236-087-11 FILTER, LOW PASS
< TRANSISTOR >
Q01 8-729-029-86 TRANSISTOR DTC124ESA
Q02 8-729-029-86 TRANSISTOR DTC124ESA
Q03 8-729-029-68 TRANSISTOR DTC114TSA
Q04 8-729-029-68 TRANSISTOR DTC114TSA
Q05 8-729-231-55 TRANSISTOR 2SC2878-AB
Q06 8-729-231-55 TRANSISTOR 2SC2878-AB
Q07 8-729-029-86 TRANSISTOR DTC124ESA
Q08 8-729-142-46 TRANSISTOR 2SC2001-LK
Q09 8-729-142-46 TRANSISTOR 2SC2001-LK
Q10 8-729-140-96 TRANSISTOR 2SD774-34
Q11 8-729-900-63 TRANSISTOR DTA124ES
Q12 8-729-029-86 TRANSISTOR DTC124ESA
Q13 8-729-029-86 TRANSISTOR DTC124ESA
Q14 8-729-029-68 TRANSISTOR DTC114TSA
Q15 8-729-029-68 TRANSISTOR DTC114TSA
Q16 8-729-029-86 TRANSISTOR DTC124ESA
Q17 8-729-029-86 TRANSISTOR DTC124ESA
Q18 8-729-029-86 TRANSISTOR DTC124ESA
Q45 8-729-194-57 TRANSISTOR 2SC945-P
Q12A 8-729-900-63 TRANSISTOR DTA124ES
Q13A 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R01 1-247-881-00 CARBON 120K 5% 1/4W
R02 1-247-881-00 CARBON 120K 5% 1/4W
R03 1-247-881-00 CARBON 120K 5% 1/4W
R04 1-247-881-00 CARBON 120K 5% 1/4W
R05 1-247-850-11 CARBON 6.2K 5% 1/4W
R06 1-247-850-11 CARBON 6.2K 5% 1/4W
R07 1-249-404-00 CARBON 82 5% 1/4W F
R08 1-249-404-00 CARBON 82 5% 1/4W F
R09 1-247-839-11 CARBON 2.2K 5% 1/4W
R10 1-247-839-11 CARBON 2.2K 5% 1/4W
R11 1-247-855-11 CARBON 10K 5% 1/4W
R12 1-247-855-11 CARBON 10K 5% 1/4W
R13 1-247-843-11 CARBON 3.3K 5% 1/4W
R14 1-247-843-11 CARBON 3.3K 5% 1/4W
R15 1-249-431-11 CARBON 15K 5% 1/4W
R16 1-249-431-11 CARBON 15] 5% 1/4W
R17 1-249-387-11 CARBON 3.3 5% 1/4W F
R18 1-247-847-11 CARBON 4.7K 5% 1/4W
R19 1-249-390-11 CARBON 5.6 5% 1/4W F
R20 1-249-432-11 CARBON 18K 5% 1/4W
R21 1-249-432-11 CARBON 18K 5% 1/4W
R22 1-249-424-11 CARBON 3.9K 5% 1/4W F
R23 1-249-432-11 CARBON 18K 5% 1/4W
R24 1-249-420-11 CARBON 1.8K 5% 1/4W F
R25 1-247-838-11 CARBON 2K 5% 1/4W
R28 1-247-855-11 CARBON 10K 5% 1/4W
R29 1-247-855-11 CARBON 10K 5% 1/4W
R30 1-247-855-11 CARBON 10K 5% 1/4W
R31 1-247-855-11 CARBON 10K 5% 1/4W
R32 1-247-843-11 CARBON 3.3K 5% 1/4W
R33 1-247-843-11 CARBON 3.3K 5% 1/4W
R34 1-249-428-11 CARBON 8.2K 5% 1/4W F
R36 1-247-863-11 CARBON 22K 5% 1/4W
R37 1-247-863-11 CARBON 22K 5% 1/4W
R38 1-249-418-11 CARBON 1.2K 5% 1/4W F
R39 1-249-418-11 CARBON 1.2K 5% 1/4W F
R40 1-247-863-11 CARBON 22K 5% 1/4W
R41 1-247-863-11 CARBON 22K 5% 1/4W
R44 1-247-883-00 CARBON 150K 5% 1/4W
R45 1-249-428-11 CARBON 8.2K 5% 1/4W F
R46 1-249-428-11 CARBON 8.2K 5% 1/4W F
R49 1-247-839-11 CARBON 2.2K 5% 1/4W
R50 1-247-839-11 CARBON 2.2K 5% 1/4W
R51 1-247-839-11 CARBON 2.2K 5% 1/4W
R52 1-247-839-11 CARBON 2.2K 5% 1/4W
R53 1-247-843-11 CARBON 3.3K 5% 1/4W
R54 1-247-843-11 CARBON 3.3K 5% 1/4W
R55 1-249-417-11 CARBON 1K 5% 1/4W F
R56 1-249-417-11 CARBON 1K 5% 1/4W F
R57 1-249-436-11 CARBON 39K 5% 1/4W
R58 1-249-431-11 CARBON 15K 5% 1/4W
R59 1-247-879-11 CARBON 100K 5% 1/4W
R60 1-249-439-11 CARBON 68K 5% 1/4W
R61 1-247-867-11 CARBON 33K 5% 1/4W
R62 1-247-883-00 CARBON 150K 5% 1/4W
R63 1-249-438-11 CARBON 56K 5% 1/4W
R64 1-249-432-11 CARBON 18K 5% 1/4W
R65 1-247-883-00 CARBON 150K 5% 1/4W
R66 1-249-430-11 CARBON 12K 5% 1/4W
R67 1-247-849-11 CARBON 5.6K 5% 1/4W
R68 1-249-431-11 CARBON 15K 5% 1/4W
R69 1-249-436-11 CARBON 39K 5% 1/4W
R70 1-247-863-11 CARBON 22K 5% 1/4W
R71 1-247-876-11 CARBON 75K 5% 1/4W
R72 1-247-876-11 CARBON 75K 5% 1/4W
R73 1-249-431-11 CARBON 15K 5% 1/4W
R74 1-249-431-11 CARBON 15K 5% 1/4W
R75 1-249-434-11 CARBON 27K 5% 1/4W
R01A 1-249-393-11 CARBON 10 5% 1/4W F
R015 1-249-409-11 CARBON 220 5% 1/4W F
