Sony TC-SD1 - Page 29

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 41 —
DOLBY FRONT MODE CONTROL
R016 1-249-409-11 CARBON 220 5% 1/4W F
R19A 1-249-390-11 CARBON 5.6 5% 1/4W F
R40A 1-247-847-11 CARBON 4.7K 5% 1/4W
R400 1-247-903-00 CARBON 1M 5% 1/4W
R401 1-249-417-11 CARBON 1K 5% 1/4W F
R402 1-249-424-11 CARBON 3.9K 5% 1/4W F
R403 1-247-855-11 CARBON 10K 5% 1/4W
R41A 1-247-847-11 CARBON 4.7K 5% 1/4W
R44A 1-247-862-11 CARBON 20K 5% 1/4W
R45A 1-249-389-11 CARBON 4.7 5% 1/4W F
R46A 1-249-389-11 CARBON 4.7 5% 1/4W F
R57A 1-247-871-11 CARBON 47K 5% 1/4W
< RELAY >
RY01 1-755-294-11 RELAY
< VARIABLE RESISTOR >
SRF01 1-238-598-11 RES, ADJ, CARBON 2.2K (PB LEVEL L)
SRF02 1-238-598-11 RES, ADJ, CARBON 2.2K (PB LEVEL R)
SRF03 1-241-768-11 RES, ADJ, CARBON 220K (BIAS CURRENT L)
SRF04 1-241-768-11 RES, ADJ, CARBON 220K (BIAS CURRENT R)
SRF11 1-238-600-11 RES, ADJ, CARBON 10K (REC LEVEL L)
SRF12 1-238-600-11 RES, ADJ, CARBON 10K (REC LEVEL R)
************************************************************
* A-2007-817-A FRONT BOARD, COMPLETE
**********************
< CONNECTOR >
CN09 1-785-783-11 CONNECTOR, FFC/FPC 19P
< LED >
LED1 8-719-072-76 LED SEL5E23C-TP15 (REV)
LED2 8-719-072-76 LED SEL5E23C-TP15 (PLAY)
LED3 8-719-072-76 LED SEL5E23C-TP15 (PAUSE)
LED4 8-719-072-76 LED SEL5E23C-TP15 (STOP)
LED5 8-719-304-83 LED SEL2410G (-10)
LED6 8-719-304-83 LED SEL2410G (-5)
LED7 8-719-304-83 LED SEL2410G (0)
LED8 8-719-812-41 LED TLR124 (+3)
LED9 8-719-812-41 LED TLR124 (+6)
LED10 8-719-058-04 LED SEL5223S-TP15 (CD SYNC)
LED11 8-719-058-04 LED SEL5223S-TP15 (REC)
LED12 8-719-300-97 LED SEL2710K (PAUSE)
LED13 8-719-311-60 LED SEL2810D-C (REW)
LED14 8-719-311-60 LED SEL2810D-C (FF)
LED15 8-719-304-83 LED SEL2410G (REV)
LED16 8-719-304-83 LED SEL2410G (PLAY)
LED17 8-719-304-83 LED SEL2410G (∞)
LED18 8-719-812-41 LED TLR124 (TAPE)
< RESISTOR >
R215 1-247-827-11 CARBON 680 5% 1/4W
R216 1-249-417-11 CARBON 1K 5% 1/4W F
R217 1-247-835-11 CARBON 1.5K 5% 1/4W
R218 1-247-839-11 CARBON 2.2K 5% 1/4W
R219 1-247-843-11 CARBON 3.3K 5% 1/4W
R220 1-247-847-11 CARBON 4.7K 5% 1/4W
R222 1-247-827-11 CARBON 680 5% 1/4W
R223 1-249-417-11 CARBON 1K 5% 1/4W F
R224 1-247-835-11 CARBON 1.5K 5% 1/4W
R230 1-249-409-11 CARBON 220 5% 1/4W F
R231 1-249-409-11 CARBON 220 5% 1/4W F
R232 1-249-409-11 CARBON 220 5% 1/4W F
R233 1-249-409-11 CARBON 220 5% 1/4W F
< SWITCH >
S1 1-572-647-11 SWITCH, KEY BOARD (STOP)
S2 1-572-647-11 SWITCH, KEY BOARD (PAUSE)
S3 1-572-647-11 SWITCH, KEY BOARD (PLAY)
S4 1-572-647-11 SWITCH, KEY BOARD (REV)
S5 1-572-647-11 SWITCH, KEY BOARD (CD SYNC)
S6 1-572-647-11 SWITCH, KEY BOARD (REC)
S9 1-572-647-11 SWITCH, KEY BOARD (FF)
S10 1-572-647-11 SWITCH, KEY BOARD (REW)
************************************************************
* 1-672-011-11 MODE CONTROL BOARD
********************
3-017-287-01 TERMINAL (RP)
< DIODE >
D001 8-719-911-19 DIODE 1N4148M
D002 8-719-911-19 DIODE 1N4148M
< IC >
IC001 3-017-289-01 PLATE, ROTARY DETECTION
< PLUNGER SOLENOID >
PM001 3-017-292-01 SOLENOID
< SWITCH >
S001 3-017-290-01 DETECT, SWITCH (FWD REC)
S002 3-017-290-01 DETECT, SWITCH (HALF)
S003 3-017-290-01 DETECT, SWITCH (CrO2)
S004 3-017-290-01 DETECT, SWITCH (METAL)
S005 3-017-290-01 DETECT, SWITCH (REV REC)
S006 3-017-291-01 MODE, SWITCH (MODE)
< RESISTOR >
R001 1-247-862-11 CARBON 20K 5% 1/4W
************************************************************
