Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 42 —
POWER POWER TRANS
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
* A-2007-823-A O/C SW BOARD, COMPLETE
***********************
< SWITCH >
S8 1-572-647-11 SWITCH, KEY BOARD (EJECT)
************************************************************
* A-2007-824-A PANEL SW BOARD, COMPLETE
*************************
< SWITCH >
S15 1-771-612-11 SWITCH, DETECTION (PANEL SW)
************************************************************
* A-2007-820-A POWER BOARD, COMPLETE
***********************
< CAPACITOR >
C31 1-162-290-31 CERAMIC 470PF 10% 50V
C32 1-162-290-31 CERAMIC 470PF 10% 50V
C48 1-126-925-11 ELECT 470uF 20% 10V
C49 1-126-925-11 ELECT 470uF 20% 10V
C50 1-164-159-11 CERAMIC 0.1uF 50V
C51 1-162-294-31 CERAMIC 0.001uF 10% 50V
C52 1-162-294-31 CERAMIC 0.001uF 10% 50V
C53 1-164-159-11 CERAMIC 0.1uF 50V
C54 1-126-943-11 ELECT 2200uF 20% 25V
C55 1-126-943-11 ELECT 2200uF 20% 25V
C56 1-126-943-11 ELECT 2200uF 20% 25V
C57 1-162-306-11 CERAMIC 0.01uF 20% 16V
C58 1-126-926-11 ELECT 1000uF 20% 10V
C59 1-126-960-11 ELECT 1uF 20% 50V
C84 1-102-129-00 CERAMIC 10000PF 10% 50V
C85 1-102-129-00 CERAMIC 10000PF 10% 50V
C86 1-102-129-00 CERAMIC 10000PF 10% 50V
C87 1-102-129-00 CERAMIC 10000PF 10% 50V
C90 1-164-159-11 CERAMIC 0.1uF 50V
C91 1-164-159-11 CERAMIC 0.1uF 50V
C90A 1-124-261-00 ELECT 10uF 20% 50V
< CONNECTOR >
* CN03 1-566-856-11 SOCKET, CONNECTOR 5P (SYSTEM CONTROL)
CN04 1-785-781-11 HEADER, PIN 8P
CN06 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN07 1-785-782-11 HEADER, PIN 10P
* CN15 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN12A 1-785-780-11 HEADER, PIN 13P
< DIODE >
D07 8-719-991-33 DIODE 1SS133T-77
D12 8-719-031-85 DIODE 1N4002L
D17 8-719-073-77 DIODE W005M
D22 8-719-031-85 DIODE 1N4002L
D23 8-719-031-85 DIODE 1N4002L
D24 8-719-031-85 DIODE 1N4002L
D25 8-719-031-85 DIODE 1N4002L
D36 8-719-991-33 DIODE 1SS133T-77
D37 8-719-991-33 DIODE 1SS133T-77
< IC >
IC04 8-759-288-53 IC LA5617
IC10 8-759-604-35 IC M5F78M05L
IC11 8-759-549-81 IC P82B715TD.112
< JACK >
JK01 1-785-822-11 JACK, PIN (TAPE)
< TRANSISTOR >
Q20 8-729-119-78 TRANSISTOR 2SC403SP-51
Q37 8-729-029-68 TRANSISTOR DTC114TSA
Q39 8-729-029-68 TRANSISTOR DTC114TSA
Q40 8-729-900-63 TRANSISTOR DTA124ES
Q41 8-729-900-63 TRANSISTOR DTA124ES
Q42 8-729-012-83 TRANSISTOR 2SK679A
Q43 8-729-012-83 TRANSISTOR 2SK679A
Q05A 8-729-231-55 TRANSISTOR 2SC2878-AB
Q06A 8-729-231-55 TRANSISTOR 2SC2878-AB
< RESISTOR >
R26 1-247-879-11 CARBON 100K 5% 1/4W
R27 1-247-879-11 CARBON 100K 5% 1/4W
R35 1-247-855-11 CARBON 10K 5% 1/4W
R42 1-247-839-11 CARBON 2.2K 5% 1/4W
R43 1-247-839-11 CARBON 2.2K 5% 1/4W
R115 1-247-855-11 CARBON 10K 5% 1/4W
R119 1-247-713-11 CARBON 1K 5% 1/4W F
R120 1-247-855-11 CARBON 10K 5% 1/4W
R121 1-247-855-11 CARBON 10K 5% 1/4W
R122 1-247-855-11 CARBON 10K 5% 1/4W
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R124 1-247-879-11 CARBON 100K 5% 1/4W
R125 1-247-855-11 CARBON 10K 5% 1/4W
R126 1-247-855-11 CARBON 10K 5% 1/4W
R213 1-247-863-11 CARBON 22K 5% 1/4W
R302 1-247-879-11 CARBON 100K 5% 1/4W
R303 1-249-417-11 CARBON 1K 5% 1/4W F
R304 1-249-417-11 CARBON 1K 5% 1/4W F
R305 1-247-879-11 CARBON 100K 5% 1/4W
R306 1-247-807-11 CARBON 100 5% 1/4W
R307 1-247-807-11 CARBON 100 5% 1/4W
R35A 1-249-417-11 CARBON 1K 5% 1/4W F
R38A 1-247-847-11 CARBON 4.7K 5% 1/4W
R39A 1-247-847-11 CARBON 4.7K 5% 1/4W
************************************************************
* 1-672-764-11 POWER TRANS BOARD
*******************
< TRANSFORMER >
! T01 1-433-657-11 TRANSFORMER, POWER
************************************************************
O/C SW PANEL SW
