Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 43 —
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
* 1-672-765-11 VR BOARD
*********
< VARIABLE RESISTOR >
VR02 1-225-749-11 RES, VAR, CARBON 50K/50K (REC LEVEL)
************************************************************
MISCELLANEOUS
**************
15 1-773-128-11 WIRE (FLAT TYPE) (19 CORE)
! 63 1-555-750-00 CORD, POWER
! 65 1-526-794-11 OUTLET, AC
HRPE9013-017-303-01 HEAD (REC/PLAY/ERASE)
M901 3-017-239-01 PULLEY (MOTOR) (LOADING)
M902 3-017-259-01 PULLEY (MOTOR)(CAPSTAN REEL)
S901 3-017-238-01 LIMITTER (SW MSS-8B)(OPEN)
S902 3-017-238-01 LIMITTER (SW MSS-8B)(CLOSE)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-790-441-11 CABLE, IC CONNECTOR 5P (SYSTEM CABLE)
3-020-441-01 BRACKET (PATCH CORD)(AUDIO CABLE)
3-864-773-11 MANUAL, INSTRUCTION (ENGLISH)
3-864-773-21 MANUAL, INSTRUCTION
(FRENCH/SPANISH) (AEP, UK, E, SP)
3-864-773-31 MANUAL, INSTRUCTION (GERMAN/DUTCH/
SWEDISH/ITALIAN/PORTUGUESE) (AEP, UK)
3-864-773-41 MANUAL, INSTRUCTION (CHINESE) (E, HK, SP)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-534-19 SCREW +B 2.6 × 8 (TYPE2)
#3 7-685-533-19 SCREW +B 2.6 × 6 (TYPE2)
#4 7-685-535-19 SCREW +B 2.6 × 10 (TYPE2)
#6 7-685-547-19 SCREW +B 3 × 10 (TYPE2)
#7 7-682-903-11 SCREW +PWH 3 × 6
#8 7-685-645-79 SCREW +P 3 × 6 TYPE2 NON-SLIT
#9 7-685-146-11 SCREW +P 3 × 8 TYPE2 NON-SLIT
#10 7-685-132-19 SCREW +P 2.6 × 5 TYPE2 NON-SLIT
#11 7-671-157-01 BALL, STAINLESS (5 DIA)
#12 7-627-551-18 SCREW,PRECISION +P 1.4 × 2
#13 7-685-105-19 SCREW +P 2 × 8 TYPE2 NON-SLIT
#14 7-621-772-10 SCREW +P 2 × 4
