WFM 1125 Option 0A/0B/0C/0D User Manual
1-1
Getting Started
This section presents information you need to set up your WFM 1125 Digital
Television Waveform Monitor Option 0A/0B/0C/0D. This section contains the
following information:
H Product Description. Gives an overview of the product capabilities.
H Options and Accessories. Lists the standard and optional accessories.
H Installation. Describes how to set up the waveform monitor for use.
H Operating Environment. Describes the environmental requirements to ensure
proper operation and long instrument life.
Product Description
The WFM 1125 Digital Television Waveform Monitor Option 0A/0B/0C/0D
measures and displays HDTV serial digital signals. The waveform monitor is a
fully digital waveform monitor with a variety of standard measurement modes
displayed on an internal VGA display. An external VGA display output is also
provided. The digital architecture of the waveform monitor allows you to save
the displayed waveform to an internal memory. In order to properly display
intermittent events that may be missed in a single-line select mode, the waveform
monitor has a persistence display feature combining information from many TV
lines, much like an analog waveform monitor.
Refer to Appendix A: Specifications, for details of the waveform monitor
performance.
The waveform monitor offers the following features:
H Supports the following system formats:
H Option 0A: 1035/60i, 1035/59.94i, 1080/60i, and 1080/59.94i
H Option 0B: 720/60p and 720/59.94p
H Option 0C: 1035/60i, 1035/59.94i, 1080/60i, 1080/59.94i, 720/60p, and
720/59.94p
H Option 0D: 1035/60i, 1035/59.94i, 1080/60i, 1080/59.94i, 1080/50i,
720/60p, 720/59.94p, 1080/30sF, 1080/29.97sF, 1080/25sF, 1080/24sF,
1080/23.98sF, 1080/24p, and 1080/23.98p
H Digital component video signal displays, parade and vector modes
Features
