Appendix A: Specifications
WFM 1125 Option 0A/0B/0C/0D User Manual
A-7
Table A-8: Field rate display
Characteristic Performance requirements Reference information
Target Signal Selected Reference Signal
Display Contents Internal Detected Field Rate
60.00 Hz 59.97 Hz to 60.03 Hz
59.94 Hz 59.91 Hz to 59.97 Hz
??.?? Hz
u60.03 Hz or t59.91 Hz
(Display Missing Reference")
Display Contents (Interlace mode of
Option 0D)
Internal Detected Field Rate
60i 59.97 Hz to 60.03 Hz
59.94i 59.91 Hz to 59.97 Hz
50i 48.024 Hz to 59.91 Hz
??.?? Unknown field late (Display Missing
Reference")
Display Contents (Segment Frame mode
of Option 0D)
Internal Detected Field Rate
30sF 95.97 Hz to 60.03 Hz
29.97sF 59.91 Hz to 59.97 Hz
25sF 48.024 Hz to 59.92 Hz
24sF 47.976 Hz to 48.024 Hz
23.98sF 47.928 Hz to 47.976 Hz
??.?? Unknown field late
(Display Missing Reference")
Display Contents (Progressive mode of
Option 0D)
Internal Detected Field Rate
60p 59.97 Hz to 60.03 Hz
59.94p 59.91 Hz to 59.97 Hz
24p 23.988 Hz to 24.012 Hz
23.98p 23.98 Hz to 23.988 Hz
??.?? Unknown field late
(Display Missing Reference")
