Sony Tektronix WFM 1125 User Manual

Appendix A: Specifications
WFM 1125 Option 0A/0B/0C/0D User Manual
A-9
Table A-12: Bowtie mode
Characteristic Performance requirements Reference information
Common Mode Rejection Ratio
uĂ44 dBĂto 15 MHz
Amplitude Error
t 0.25 %
Internal Timing Match Zero error (coĆsited data)
Table A-13: Status display mode
Characteristic Performance requirements Reference information
Display Capability 4000 words
Format HEX and DEC
Table A-14: Save and display mode
Characteristic Performance requirements Reference information
Delay Time (from time of button pushed)
t 3 frames
Length of Reference Memories 1 frame
Table A-15: Warning display
Characteristic Performance requirements Reference information
CRC Error LED LED lights for 0.5 seconds at error detected.
CRC Error Count CRC error count, elapsed time in this mode,
and the time of latest error detected are
displayed.
Resolution 10 ms
GAMUT Error LED lights for 10 milliseconds at error
detected. Error check timing is made at the
same time as the waveform is displayed.
Warning is derived from input data.
Error Detection Level
Positive
Negative
735 mV ±7 mV (105 % of legal RGB, Nom),
-35 mV ±7mV.
