Functional Overview
2-8
WFM 1125 Option 0A/0B/0C/0D User Manual
Table 2-2: Rear panel functions (Cont.)
Rear panel items DescriptionsItem name
VGA OUTPUT connector Provides a VGA signal output identical to the signal displayed on
the screen. Connect this output to a VGA monitor or projector to
display screen information, or connect the output to a video
printer to make a screen hardcopy.
RSĆ232C connector This 9Ćpin subminiature DĆtype connector provides a serial
interface for data output and calibration.
