8-3
REF NO. PART NO. DESCRIPTION REMARK
1 4-050-931-01 CABINET (UPPER)(14G5)
1 4-050-967-01 CABINET (UPPER)(14G1)
2 * 4-053-287-11 GASKET
3 4-063-969-01 SCREW (OS), CASE, CLAW
4 4-050-933-01 CABINET (LEFT)
5 4-050-932-01 CABINET (RIGHT)
6 * 4-053-255-01 GASKET (S), EMI
7 * 4-053-254-01 GASKET (L), EMI
8 X-3642-018-3 HANDLE ASSY 9
9 * 3-642-047-01 STOP, HANDLE
10 * 4-050-928-01 BRACKET, HANDLE
11 * X-4035-465-1 PANEL ASSY, REAR (14G1)
11 * X-4035-466-2 PANEL ASSY, REAR (14G5)
12 * X-4033-104-1 PANEL ASSY, BLANK 13,14
13 * 4-050-804-01 SCREW, PANEL STOPPER
14 * 3-648-057-00 NUT (ISO-4), U
15 * 4-050-913-01 INSULATOR (ANODE)
16 * A-1373-641-A YA MOUNT
17 * 4-050-876-01 PLATE, LIGHT INTERCEPTION
18 * A-1373-638-A YB MOUNTED (14G1)
18 * A-1373-661-A YB MOUNT (14G5)
19 * A-1373-636-A YC MOUNTED (14G1)
19 * A-1373-643-A YC MOUNT (14G5)
20 * 4-061-920-01 INSULATOR, YC
21 X-4033-128-1 MASK (4:3) ASSY
22 * X-4033-276-1 GUARD ASSY, HARNESS(L)(14G1)
23 * X-4033-277-1 GUARD ASSY, HARNESS(S)(14G1)
24 X-4033-145-1 BEZEL ASSY (14G1)
25 X-4033-130-1 BEZEL ASSY (14G5)
26 4-050-922-01 BASE, HANDLE (14G5)
27 * 4-337-212-11 HANDLE (14G5)
28 4-050-851-01 KNOB, CONTROL (14G5)
29 * A-1372-133-A MOUNTED PWB, HA (14G5)
30 * 4-050-925-01 BRACKET (RIGHT), BEZEL (14G5)
31 * A-1372-134-A MOUNTED PWB, HB (14G5)
32 * 4-050-924-01 BRACKET (LEFT), BEZEL (14G5)
33 * A-1375-155-A HC COMPLETE PWB (14G5)
34 1-500-249-11 BEAD, FERRITE (CASE)(14G5)
BEZEL, CABINET
