8-9
REF NO. PART NO. DESCRIPTION REMARK
151 X-4033-308-1 CABINET ASSY, TOP 152
152 4-050-837-01 CABINET, TOP
153 4-063-969-01 SCREW (OS), CASE, CLAW
154 X-4033-310-1 CABINET ASSY, LEFT 155
155 4-050-840-01 CABINET, LEFT
156 * X-4033-324-2 BLIND COVER ASSY 157,158
157 4-050-836-01 COVER, BLIND
158 * 3-342-839-02 CUSHION
159 X-4033-309-1 CABINET ASSY, RIGHT 160
160 4-050-841-01 CABINET, RIGHT
161 X-3642-018-3 HANDLE ASSY 162
162 * 3-642-047-01 STOP, HANDLE
163 * X-4035-466-1 PANEL ASSY, REAR
164 4-050-821-01 ESCUTCHEON
165 * X-4033-104-1 PANEL ASSY, BLANK 166,167
166 * 4-050-804-01 SCREW, PANEL STOPPER
167 3-648-057-00 NUT (ISO-4), U
168 1-500-278-11 FILTER, CLAMP (FERRITE CORE)
169 * 4-050-830-01 BRACKET, BEZEL
170 * A-1373-641-A YA MOUNT
171 * 4-050-876-01 PLATE, LIGHT INTERCEPTION
172 * A-1373-642-A YB MOUNT
173 * A-1373-643-A YC MOUNT
174 X-4033-111-1 BEZEL ASSY 175
175 4-051-061-02 HOLDER, MASK
176 X-4033-112-1 MASK (4:3) ASSY
BEZEL, CABINET
To Next Page
