REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
9-4
BC
IC13 8-759-186-47 IC TC74VHC138F
IC14 8-759-289-43 IC LTC490CS8
IC15 8-759-081-46 IC TC74VHCU04F
IC16 8-759-186-43 IC TC74VHC123AF
IC17 8-759-925-73 IC SN74HC03NS
IC19 8-759-236-19 IC TC74HC151AF(EL)
IC20 8-759-236-19 IC TC74HC151AF(EL)
IC21 8-759-236-19 IC TC74HC151AF(EL)
IC22 8-759-346-05 IC µPD71051GU-10-E2
IC23 8-759-346-05 IC µPD71051GU-10-E2
IC24 8-759-346-05 IC µPD71051GU-10-E2
IC25 8-759-289-45 IC LTC485CS8
IC26 8-759-289-45 IC LTC485CS8
IC27 8-759-252-59 IC MAX202CSE
IC28 8-759-252-59 IC MAX202CSE
IC29 8-759-186-77 IC TC74VHC541F
IC30 8-759-186-24 IC TC74VHC4040F(EL)
IC31 8-759-081-46 IC TC74VHCU04F
IC32 8-759-925-75 IC SN74HC05ANS
IC33 8-759-925-75 IC SN74HC05ANS
IC34 8-759-007-56 IC MC74HC30F
IC35 8-759-186-77 IC TC74VHC541F
IC36 8-759-252-59 IC MAX202CSE
IC37 8-759-182-91 IC PQ12TZ5U
IC51 8-759-700-65 IC NJM79L05A
IC52 8-759-144-82 IC µPC2405HF
IC61 8-759-186-43 IC TC74VHC123AF
IC62 8-759-195-02 IC TC7S86F-TE85L
IC63 8-759-011-65 IC MC74HC4053F
IC104 8-759-186-24 IC TC74VHC4040F(EL)
IC105 8-752-357-15 IC CXD2343S
IC106 8-759-186-53 IC TC74VHC163F
IC109 8-752-334-64 IC CXD1171M
IC110 8-759-236-55 IC TC74HC166AF(EL)
IC111 8-759-011-65 IC MC74HC4053F
IC113 8-759-186-39 IC TC74VHC74F
IC114 8-759-295-09 IC TLC2932IPW
IC115 8-759-185-64 IC TC74VHC10F(EL)
IC116 8-759-011-65 IC MC74HC4053F
IC117 8-759-081-42 IC TC74VHC00F
IC119 8-759-011-65 IC MC74HC4053F
IC120 8-752-321-16 IC CXD1030M
IC121 8-759-081-46 IC TC74VHCU04F
IC122 8-759-081-44 IC TC74VHC04F
IC123 8-759-186-39 IC TC74VHC74F
IC124 8-759-328-12 IC Z8622812PSC
IC125 8-759-925-75 IC SN74HC05ANS
IC401 8-759-988-13 IC LM393PS
<CHIP CONDUCTOR>
JR14 1-216-296-91 SHORT 0
JR15 1-216-295-91 SHORT 0
JR114 1-216-296-91 SHORT 0
JR115 1-216-296-91 SHORT 0
JR116 1-216-296-91 SHORT 0
JR117 1-216-296-91 SHORT 0
JR118 1-216-296-91 SHORT 0
JR119 1-216-296-91 SHORT 0
<COIL>
L1 1-410-202-51 INDUCTOR CHIP 6.8µH
L201 1-412-537-31 INDUCTOR 100µH
<FILTER>
LPF101 1-239-289-11 FILTER, LOW PASS
<TRANSISTOR>
Q1 1-801-806-11 TRANSISTOR DTC144EK-T146
Q2 8-729-901-06 TRANSISTOR DTA144EK
Q3 8-729-901-06 TRANSISTOR DTA144EK
Q4 1-801-806-11 TRANSISTOR DTC144EK-T146
Q5 1-801-806-11 TRANSISTOR DTC144EK-T146
Q6 8-729-122-13 TRANSISTOR 2SA1221-K
Q7 8-729-122-13 TRANSISTOR 2SA1221-K
Q8 1-801-806-11 TRANSISTOR DTC144EK-T146
Q9 8-729-921-12 TRANSISTOR 2SD1834
Q10 1-801-806-11 TRANSISTOR DTC144EK-T146
Q51 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q52 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-901-06 TRANSISTOR DTA144EK
Q104 8-729-901-06 TRANSISTOR DTA144EK
Q106 8-729-216-22 TRANSISTOR 2SA1162-G
Q107 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q108 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q109 8-729-216-22 TRANSISTOR 2SA1162-G
Q110 8-729-901-06 TRANSISTOR DTA144EK
Q111 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q112 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q113 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q114 8-729-901-06 TRANSISTOR DTA144EK
Q115 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q116 1-801-806-11 TRANSISTOR DTC144EK-T146
Q151 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q152 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q403 8-729-921-12 TRANSISTOR 2SD1834
<RESISTOR>
R1 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6 1-216-073-00 RES,CHIP 10K 5% 1/10W
R7 1-216-097-91 RES,CHIP 100K 5% 1/10W
R8 1-216-097-91 RES,CHIP 100K 5% 1/10W
R9 1-216-097-91 RES,CHIP 100K 5% 1/10W
R10 1-216-121-91 RES,CHIP 1M 5% 1/10W
R11 1-216-073-00 RES,CHIP 10K 5% 1/10W
R12 1-216-049-91 RES,CHIP 1K 5% 1/10W
R13 1-216-049-91 RES,CHIP 1K 5% 1/10W
R14 1-216-049-91 RES,CHIP 1K 5% 1/10W
R15 1-216-049-91 RES,CHIP 1K 5% 1/10W
R16 1-216-073-00 RES,CHIP 10K 5% 1/10W
R17 1-216-073-00 RES,CHIP 10K 5% 1/10W
R18 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
