Sony TRINITRON BVM-14G1A - Page 118

REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
9-6
BC BK
R204 1-216-077-00 RES,CHIP 15K 5% 1/10W
R300 1-216-073-00 RES,CHIP 10K 5% 1/10W
R301 1-216-073-00 RES,CHIP 10K 5% 1/10W
R302 1-216-073-00 RES,CHIP 10K 5% 1/10W
R303 1-216-073-00 RES,CHIP 10K 5% 1/10W
R311 1-216-025-91 RES,CHIP 100 5% 1/10W
R312 1-216-025-91 RES,CHIP 100 5% 1/10W
R313 1-216-025-91 RES,CHIP 100 5% 1/10W
R314 1-216-025-91 RES,CHIP 100 5% 1/10W
R401 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R402 1-216-073-00 RES,CHIP 10K 5% 1/10W
R403 1-217-671-11 RES,CHIP 1 5% 1/10W
R404 1-217-671-11 RES,CHIP 1 5% 1/10W
R405 1-217-671-11 RES,CHIP 1 5% 1/10W
R406 1-216-073-00 RES,CHIP 10K 5% 1/10W
R407 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R408 1-216-073-00 RES,CHIP 10K 5% 1/10W
R409 1-216-073-00 RES,CHIP 10K 5% 1/10W
R410 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R411 1-216-097-91 RES,CHIP 100K 5% 1/10W
R551 1-216-049-91 RES,CHIP 1K 5% 1/10W
R552 1-216-049-91 RES,CHIP 1K 5% 1/10W
R553 1-216-049-91 RES,CHIP 1K 5% 1/10W
R554 1-216-049-91 RES,CHIP 1K 5% 1/10W
R555 1-216-049-91 RES,CHIP 1K 5% 1/10W
R556 1-216-049-91 RES,CHIP 1K 5% 1/10W
R557 1-216-049-91 RES,CHIP 1K 5% 1/10W
R558 1-216-049-91 RES,CHIP 1K 5% 1/10W
<VARIABLE RESISTOR>
RV101 1-238-787-11 RES, ADJ, CERMET 10K
<RELAY>
RY401 1-515-716-11 RELAY (TQ2-5V)
<TEST PIN>
TP1 1-537-864-11 PIN, POST
TP3 1-537-864-11 PIN, POST
TP5 1-537-864-11 PIN, POST
TP6 1-537-864-11 PIN, POST
TP7 1-537-864-11 PIN, POST
TP8 1-537-864-11 PIN, POST
TP9 1-537-864-11 PIN, POST
TP10 1-537-864-11 PIN, POST
TP11 1-537-864-11 PIN, POST
TP12 1-537-864-11 PIN, POST
TP13 1-537-864-11 PIN, POST
<CRYSTAL>
X1 1-767-892-21 VIBRATOR, CRYSTAL (20MHz)
X2 1-760-464-11 VIBRATOR, CRYSTAL (4.9152MHz)
X101 1-767-655-21 VIBRATOR, CRYSTAL (14.31818MHz)
X102 1-767-891-21 VIBRATOR, CRYSTAL (14.1875MHz)
X103 1-760-429-11 VIBRATOR, CRYSTAL (14.5MHz)
*************************************************************
* A-1135-921-A BK COMPL (20G1)
****************
* A-1135-941-A BK COMPLE (14G1/14G5)
****************
* X-4033-105-1 PANEL (BK) ASSY, CONNECTOR
* 3-648-057-00 NUT (ISO-4), U
* 4-050-814-01 SHIELD, PWB
* 4-053-411-01 SHIELD (BK), PWB (14G1/14G5)
* 4-057-770-01 INSULATOR
4-382-854-01 SCREW (M3X8), P, SW (+)(14G1/14G5)
4-623-699-01 SCREW (3X5)
* 4-625-464-01 SUPPORT, FITTING, MB
7-682-566-04 SCREW +B 4X20
7-682-647-09 SCREW +PS 3X6
7-685-872-09 SCREW +BVTT 3X8 (S)
<CAPACITOR>
C1 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C3 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C5 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C7 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C8 1-126-396-11 ELECT CHIP 47MF 20% 16V
C9 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C11 1-126-396-11 ELECT CHIP 47MF 20% 16V
C12 1-126-396-11 ELECT CHIP 47MF 20% 16V
C13 1-126-396-11 ELECT CHIP 47MF 20% 16V
C14 1-126-397-11 ELECT CHIP 33MF 20% 25V
C15 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C100 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C101 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C102 1-115-155-11 ELECT CHIP 22MF 20% 16V
C103 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C104 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C122 1-126-396-11 ELECT CHIP 47MF 20% 16V
C128 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C129 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C130 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C131 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C140 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C141 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C142 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C143 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C144 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C145 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C146 1-126-392-11 ELECT CHIP 100MF 20% 6.3V
C147 1-126-392-11 ELECT CHIP 100MF 20% 6.3V
C154 1-126-390-11 ELECT CHIP 22MF 20% 6.3V
C160 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C161 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C162 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C163 1-163-091-00 CERAMIC CHIP 8PF 0.25PF 50V
C164 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C165 1-164-222-11 CERAMIC CHIP 0.22MF 25V
C166 1-164-700-11 CERAMIC CHIP 0.68MF 16V
C167 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C168 1-163-075-00 CERAMIC CHIP 0.047MF 10% 25V
C169 1-163-075-00 CERAMIC CHIP 0.047MF 10% 25V
