Sony TRINITRON BVM-14G1A - Page 140

REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
9-28
G
C325 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C802 1-164-005-11 CERAMIC CHIP 0.47MF 16V
C804 1-107-888-11 ELECT 47MF 20% 25V
C805 1-107-906-11 ELECT 10MF 20% 50V
C806 1-107-888-11 ELECT 47MF 20% 25V
C807 1-107-906-11 ELECT 10MF 20% 50V
C809 1-107-906-11 ELECT 10MF 20% 50V
C810 1-107-906-11 ELECT 10MF 20% 50V
C901 ! 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C902 ! 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C903 1-107-888-11 ELECT 47MF 20% 25V
C904 1-128-526-11 ELECT 100MF 20% 16V
<CONNECTOR>
CN1 ! 1-564-321-00 PIN, CONNECTOR 2P
CN2 1-568-106-11 PIN, CONNECTOR 4P
CN3 1-774-523-11 PIN, CONNECTOR (PC BOARD) 64P
<DIODE>
D1 ! 8-719-510-53 DIODE D4SB60L
D2 8-719-110-52 DIODE RD20ESB1
D3 8-719-110-61 DIODE RD24ESB1
D4 8-719-053-43 DIODE SLR-325VCT31
D5 8-719-510-02 DIODE D1NS4
D6 8-719-510-02 DIODE D1NS4
D8 8-719-404-49 DIODE MA111
D9 8-719-510-02 DIODE D1NS4
D31 8-719-510-02 DIODE D1NS4
D32 8-719-106-23 DIODE RD7.5M-B2
D33 8-719-510-02 DIODE D1NS4
D34 8-719-110-61 DIODE RD24ESB1
D35 8-719-510-02 DIODE D1NS4
D36 8-719-029-04 DIODE D5L60
D101 8-719-911-19 DIODE 1SS119-25
D102 8-719-404-49 DIODE MA111
D103 8-719-053-43 DIODE SLR-325VCT31
D104 8-719-404-49 DIODE MA111
D105 8-719-158-49 DIODE RD12SB2
D106 8-719-110-50 DIODE RD18ESB3
D202 8-719-988-55 DIODE RGP15K-6179
D203 8-719-979-58 DIODE EGP10D
D204 8-719-510-37 DIODE D5LC20U
D205 8-719-060-27 DIODE SLR-325MCT31
D206 8-719-510-37 DIODE D5LC20U
D207 8-719-510-37 DIODE D5LC20U
D208 8-719-510-37 DIODE D5LC20U
D209 8-719-510-37 DIODE D5LC20U
D210 8-719-404-49 DIODE MA111
D211 8-719-404-49 DIODE MA111
D212 8-719-110-50 DIODE RD18ESB3
D300 8-719-404-49 DIODE MA111
D302 8-719-988-55 DIODE RGP15K-6179
D303 8-719-031-79 DIODE D5SC4M
D304 8-719-029-04 DIODE D5L60
D305 8-719-404-49 DIODE MA111
D306 8-719-404-49 DIODE MA111
D307 8-719-110-50 DIODE RD18ESB3
D801 8-719-060-27 DIODE SLR-325MCT31
D803 8-719-404-49 DIODE MA111
D804 8-719-404-49 DIODE MA111
D806 8-719-404-49 DIODE MA111
D807 8-719-404-49 DIODE MA111
D810 8-719-106-23 DIODE RD7.5M-B2
D811 8-719-159-13 DIODE RD5.1SB3-T2
D812 8-719-159-13 DIODE RD5.1SB3-T2
D901 8-719-911-19 DIODE 1SS119-25
<FUSE>
F1 ! 1-576-231-11 FUSE (H.B.C.) 4A/250V
F201 ! 1-533-987-11 FUSE, MICRO 5A/125V
F202 ! 1-533-987-11 FUSE, MICRO 5A/125V
<FERRITE BEAD>
FB31 1-410-396-41 FERRITE 0µH
FB32 1-410-396-41 FERRITE 0µH
FB33 1-410-396-41 FERRITE 0µH
FB34 1-410-396-41 FERRITE 0µH
FB201 1-410-396-41 FERRITE 0µH
FB301 1-410-396-41 FERRITE 0µH
<IC>
IC1 8-759-982-15 IC RC7815FA
IC31 8-759-354-43 IC TK83854D
IC32 8-759-100-96 IC µPC4558G2
IC101 8-759-988-13 IC LM393PS
IC201 8-759-914-04 IC TL494CNS
IC202 8-759-908-15 IC TL431CLP
IC203 8-759-908-15 IC TL431CLP
IC301 8-759-914-04 IC TL494CNS
IC302 8-759-908-15 IC TL431CLP
IC801 8-759-085-67 IC LM339NS
IC802 8-759-908-15 IC TL431CLP
IC803 8-759-424-24 IC MC74HC147FEL
IC804 8-759-908-15 IC TL431CLP
IC901 8-759-231-58 IC TA7812S
<COIL>
L201 1-406-661-11 INDUCTOR 0µH
L301 1-406-661-11 INDUCTOR 0µH
L302 1-406-661-11 INDUCTOR 0µH
<PHOTO COUPLER>
PH201 ! 8-749-010-64 PHOTO COUPLER PC123F2
PH301 ! 8-749-010-64 PHOTO COUPLER PC123F2
PH802 ! 8-749-010-64 PHOTO COUPLER PC123F2
PH803 ! 8-749-010-64 PHOTO COUPLER PC123F2
PH901 ! 8-749-010-64 PHOTO COUPLER PC123F2
<TRANSISTOR>
Q1 8-729-043-95 TRANSISTOR 2SC3840(3)
Q2 8-729-043-95 TRANSISTOR 2SC3840(3)
Q4 8-729-043-95 TRANSISTOR 2SC3840(3)
Q5 8-729-118-44 TRANSISTOR 2SA1413-K
Q6 8-729-027-87 TRANSISTOR 2SB1261-K
Q7 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q8 8-729-118-44 TRANSISTOR 2SA1413-K
Q9 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q31 8-729-044-22 TRANSISTOR 2SK2209-01R-F165
Q32 8-729-120-28 TRANSISTOR 2SC1623-L5L6
