9-35
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
P MOUNT (not supplyed)
*******
<CAPACITOR>
C901 1-137-150-11 MYLAR 0.01MF 10% 100V
C902 1-137-150-11 MYLAR 0.01MF 10% 100V
C903 1-136-157-00 FILM 0.022MF 5% 50V
<CONNECTOR>
CN901 * 1-573-986-11 PIN, CONNECTOR (PC BOARD) 5P
CN902 * 1-564-514-11 PLUG, CONNECTOR 11P
CN903 * 1-508-766-00 PIN, CONNECTOR (5MM PITCH) 4P
CN904 1-766-240-11 PIN, CONNECTOR (PC BOARD) 2P
<DIODE>
D901 8-719-302-43 DIODE EL1Z
<NEON LAMP>
NL901 1-519-526-11 LAMP, NEON
NL902 1-519-526-11 LAMP, NEON
<RESISTOR>
R901 1-215-437-00 METAL 4.7K 1% 1/4W
R902 1-215-437-00 METAL 4.7K 1% 1/4W
R903 1-215-425-00 METAL 1.5K 1% 1/4W (20G1)
R903 1-215-427-00 METAL 1.8K 1% 1/4W
(14G1/14G5)
R904 1-215-437-00 METAL 4.7K 1% 1/4W
R905 1-215-437-00 METAL 4.7K 1% 1/4W
R906 1-215-425-00 METAL 1.5K 1% 1/4W (20G1)
R906 1-215-427-00 METAL 1.8K 1% 1/4W
(14G1/20G1)
R907 1-249-377-11 CARBON 0.47 5% 1/4W F
R908 1-249-425-11 CARBON 4.7K 5% 1/4W
R909 1-247-887-00 CARBON 220K 5% 1/4W
<TRANSFORMER>
T901 ! X-4035-493-1 FBT ASSY, NX-4141//J1F4 (20G1)
T901 ! X-4035-494-1 FBT ASSY, NX-4141//J1F4 (14G1/14G5)
*************************************************************
* A-1390-771-A TA MOUNT
****************
<CONNECTOR>
CN11 1-774-525-11 SOCKET, CONNECTOR 64P
CN12 1-774-525-11 SOCKET, CONNECTOR 64P
CN13 1-774-525-11 SOCKET, CONNECTOR 64P
CN14 1-774-537-11 CONNECTOR PIN (PC BOARD) 50P
CN15 * 1-564-514-11 PLUG, CONNECTOR 11P
CN16 1-564-511-11 PLUG, CONNECTOR 8P
CN17 * 1-564-507-11 PLUG, CONNECTOR 4P
CN18 * 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN19 * 1-564-505-11 PLUG, CONNECTOR 2P
CN20 1-564-506-11 PLUG, CONNECTOR 3P
*************************************************************
* A-1390-772-A TB MOUNT
****************
<CAPACITOR>
C101 1-107-877-11 ELECT 1000MF 20% 10V
<CONNECTOR>
CN1 1-774-525-11 SOCKET, CONNECTOR 64P
CN2 1-774-525-11 SOCKET, CONNECTOR 64P
CN3 1-774-525-11 SOCKET, CONNECTOR 64P
CN4 1-774-537-11 CONNECTOR PIN (PC BOARD) 50P
CN5 1-774-525-11 SOCKET, CONNECTOR 64P
CN6 * 1-564-521-11 PLUG, CONNECTOR 6P
CN7 1-564-523-11 PLUG, CONNECTOR 8P
CN8 1-564-524-11 PLUG, CONNECTOR 9P
<COIL>
L101 1-406-661-11 INDUCTOR 0µH
*************************************************************
* A-1373-641-A YA MOUNT
****************
<CONNECTOR>
CN101 1-564-517-11 PLUG, CONNECTOR 2P
<DIODE>
D101 8-719-061-96 DIODE SLR-325DCT31
D102 8-719-061-96 DIODE SLR-325DCT31
D103 8-719-061-96 DIODE SLR-325DCT31
D104 8-719-061-96 DIODE SLR-325DCT31
D105 8-719-061-96 DIODE SLR-325DCT31
<RESISTOR>
R101 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R102 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R103 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R104 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R105 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R106 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R107 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R108 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R109 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R110 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
*************************************************************
* A-1373-638-A YB MOUNT (14G1)
****************
* A-1373-642-A YB MOUNT (14G5/20G1)
****************
<DIODE>
D201 8-719-061-96 DIODE SLR-325DCT31
D202 8-719-053-43 DIODE SLR-325VCT31
D203 8-719-060-27 DIODE SLR-325MCT31
*************************************************************
P TA TB YA YB
