Menu Structure
Chapter 2 Menu
SYSTEM CONFIGURATION [D] Sets the system of the remote control function, LAN, etc. (page
43)
NETWORK [D1] Sets the IP address, subnet mask and default gateway. (page 44)
PARALLEL REMOTE [D2] Sets the remote control function. (page 44)
POWER [D3] Sets the condition of the monitor when the main power or
MONITOR I/1 switch is turned on. (page 45)
BLANKING SETTINGS [D4] Adjusts the data for the picture. (page 45)
ON SCREEN SET [D5] Sets the data for the screen display. (page 45)
PASSWORD [D6] Sets the passwords for the menu. (page 46)
GAMMA SW Sets the gamma switch. (page 44)
MAINTENANCE [D7] Displays the menu for maintenance. (page 46)
INSTALLATION SETTINGS [E] Sets the initial value of landing, alignment, etc. (page 46)
LANDING ADJUST [E1] Corrects the shift of beam landing caused by the earths
magnetism. (page 47)
ALIGNMENT [E2] Adjusts the position and size of the picture. (page 47)
DIGITAL UNIFORMITY ADJ [E3] Adjusts the color unevenness of the CRT. (page 50)
FILE MANAGEMENT [F] Saves, copies and deletes the system data. (page 52)
SAVE TO [F1] Writes the data. (page 53)
COPY FROM [F2] Reads or copies the data. (page 53)
DELETE [F3] Deletes the file. (page 53)
DATA MAINTENANCE [F4] Services the system data. (page 53)
STATUS [G] Displays the information about the monitor or options installed in
the monitor. (page 54)
CH STATUS [G1] Displays the information of the used channel. (page 55)
SLOT STATUS [G2] Displays the data about the optional board installed in the option
slot 1 to 3. (page 55)
MODEL NAME Displays the model name. (page 55)
SERIAL NO Displays the serial number. (page 55)
SOFTWARE VERSION Displays the software version. (page 55)
OPERATION TIME Displays the operation time. (page 55)
CRT TURN ON TIME Displays how long the CRT is used. (page 55)
IP ADDR Displays the IP address of the monitor. (page 55)
CONTROLLER STATUS [G3] Displays the information on the controller. (page 55)
CONTROLLER [H] Sets the network of the controller. (page 56)
MONITOR ID DISPLAY [H1] Sets the display method of the monitor select display window.
(page 56)
NETWORK SETTING [H2] Displays the NETWORK SETTING menu. (page 56)
NETWORK SW Sets the Ethernet connections. (page 56)
SNMP SETTINGS [H3] Sets CONTACT, NAME, LOCATION and TRAP. (page 56)
KEY PROTECT [I] Sets whether or not to lock the buttons on the control unit. (page
57)
