Sony Trinitron CPD-E500 - SECTION 2 DISASSEMBLY; 2-1. CABINET REMOVAL; 2-2. D BOARD REMOVAL

CPD-E500/E500E
Top cover
Video shield
6
8
4
3
2
Two
claws
3
Two claws
CPD-E500 (U/C)
Bezel assembly Bezel assembly
Cabinet
Cabinet
Cabinet
1
Pig tail cover
Three screws
(+ BVTT 4 x 8)
7
Four screws
(+ BVTT 4 x 8)
5
Two screws
(+ BVTP 4 x 16)
Push in the tip of a screwdriver
about 5mm to unlock the claw.
A
B
Three screws
(+ BVTT 4 x 8)
Two screws
(+ BVTP 3 x 12)
D board
Screw
(+ P 3.5 x 20)
Open the D block in the direction
of the arrow . and remove of
the arrow .
Two hooks
5
A
B
CN504
CN505
GND
1
2
3
4
2-1. CABINET REMOVAL
SECTION 2
DISASSEMBLY
2-2. D BOARD REMOVAL
2-1
