Sony Trinitron CPD-E500 - Page 47

CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-2
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
C431 1-163-275-11 CERAMIC CHIP0.001µF 5% 50V
C432 1-164-489-11 CERAMIC CHIP0.22µF 10% 16V
C433 1-162-318-11 CERAMIC 0.001µF 10% 500V
C434 1-162-318-11 CERAMIC 0.001µF 10% 500V
C435 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C436 1-164-489-11 CERAMIC CHIP0.22µF 10% 16V
C437 1-126-934-11 ELECT 220µF 20% 16V
[U/C]
C437 1-126-935-11 ELECT 470µF 20% 16V
[AEP]
C438 1-115-339-11 CERAMIC CHIP0.1µF 10% 50V
C440 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C441 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C442 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C443 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C444 1-162-318-11 CERAMIC 0.001µF 10% 500V
C446 1-104-664-11 ELECT 47µF 20% 25V
C449 1-109-982-11 CERAMIC CHIP1µF 10% 10V
C450 1-107-823-11 CERAMIC CHIP0.47µF 10% 16V
C456 1-164-489-11 CERAMIC CHIP0.22µF 10% 16V
[AEP]
C457 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C458 1-115-339-11 CERAMIC CHIP0.1µF 10% 50V
C459 1-128-560-11 ELECT 22µF 20% 100V
C462 1-115-339-11 CERAMIC CHIP0.1µF 10% 50V
C463 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C464 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C467 1-107-957-11 ELECT 1µF 20% 250V
<CONNECTOR>
CN401 1-793-183-11 CONNECTOR, D SUB 15P [AEP]
CN402*1-564-509-11 PLUG, CONNECTOR 6P
CN403 1-784-463-11 CONNECTOR, FFC/FPC 21P
CN405*1-564-524-11 PLUG, CONNECTOR 9P
CN406*1-766-179-11 PIN, CONNECTOR (PC BOARD) 2P
<DIODE>
D101 8-719-062-51 DIODE 1PS226-115
D102 8-719-062-51 DIODE 1PS226-115 [AEP]
D103 8-719-066-10 DIODE 1PS181-115
D105 8-719-051-85 DIODE HSS83TD
D106 8-719-052-12 DIODE 1SS376TE-17
D107 8-719-052-12 DIODE 1SS376TE-17
D201 8-719-062-51 DIODE 1PS226-115
D202 8-719-062-51 DIODE 1PS226-115 [AEP]
D203 8-719-066-10 DIODE 1PS181-115
D205 8-719-051-85 DIODE HSS83TD
D206 8-719-052-12 DIODE 1SS376TE-17
D207 8-719-052-12 DIODE 1SS376TE-17
D301 8-719-062-51 DIODE 1PS226-115
D302 8-719-062-51 DIODE 1PS226-115 [AEP]
D303 8-719-066-10 DIODE 1PS181-115
D305 8-719-051-85 DIODE HSS83TD
D306 8-719-052-12 DIODE 1SS376TE-17
D307 8-719-052-12 DIODE 1SS376TE-17
D402 8-719-066-11 DIODE 1PS184-115
D403 8-719-982-36 ZENER DIODE MTZJ-39B
D405 8-719-911-19 DIODE 1SS119-25
D406 8-719-062-51 DIODE 1PS226-115
D407 8-719-062-51 DIODE 1PS226-115
<FERRITE BEAD>
FB102 1-500-419-22 FERRITE
FB202 1-500-419-22 FERRITE
FB302 1-500-419-22 FERRITE
FB402 1-412-911-11 FERRITE 1.1µH
FB403 1-412-911-11 FERRITE 1.1µH
FB404 1-412-911-11 FERRITE 1.1µH
FB405 1-412-911-11 FERRITE 1.1µH
FB406 1-412-911-11 FERRITE 1.1µH
FB411 1-412-911-11 FERRITE 1.1µH
<IC>
IC401 8-759-584-87 IC M52757FP-TP
IC402 8-759-584-86 IC M52749FP-TP
IC403 8-749-015-91 IC FA4301
IC404 8-759-585-72 IC CXD9514M
IC405 8-759-701-01 IC NJM2904M
IC406 8-749-015-92 IC H8D2972
IC407 8-759-925-74 IC SN74HC04ANS
<COIL>
L402 1-412-529-11 INDUCTOR 22µH
L403 1-412-537-31 INDUCTOR 100µH
L404 1-414-940-21 INDUCTOR 100µH
L405 1-412-529-11 INDUCTOR 22µH
<IC LINK>
PS401!1-533-590-31 LINK, IC (1A/90V AC, 60V DC)
<TRANSISTOR>
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q201 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 8-729-050-41 TRANSISTOR 2SJ360TE12L
Q406 8-729-216-22 TRANSISTOR 2SA1162-G
Q407 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q410 8-729-032-61 TRANSISTOR 2SC5022-02
<RESISTOR>
R101 1-215-394-00 METAL 75 1% 1/4W
R103 1-215-394-00 METAL 75 1% 1/4W
[AEP]
R105 1-216-017-91 RES,CHIP 47 5% 1/10W
R106 1-216-017-91 RES, CHIP 47 5% 1/10W
[AEP]
