CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-8
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
<CONNECTOR>
CN501*1-564-509-11 PLUG, CONNECTOR 6P
CN502*1-564-510-11 PLUG, CONNECTOR 7P
CN503*1-508-879-11 BASE POST
CN504 1-784-786-11 CONNECTOR, FFC 25P
CN505 1-784-786-11 CONNECTOR, FFC 25P
CN506 1-764-101-11 PIN, CONNECTOR (PC BOARD) 2P
CN508*1-564-511-11 PLUG, CONNECTOR 8P
CN509*1-778-955-11 PIN, CONNECTOR (PC BOARD) 10P
<DIODE>
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-110-36 ZENER DIODE RD13ESB2
D506 8-719-991-33 DIODE 1SS133T-77
D507 8-719-063-89 DIODE YG911S3R
D508 8-719-031-79 DIODE D5SC4M
D509 8-719-991-33 DIODE 1SS133T-77
D510 8-719-109-85 ZENER DIODE RD5.1ESB2
D511 8-719-066-36 DIODE FMQ-G5GS
D512 8-719-988-61 DIODE 1SS355TE-17
D513 8-719-991-33 DIODE 1SS133T-77
D514 8-719-991-33 DIODE 1SS133T-77
D515 8-719-109-89 ZENER DIODE RD5.6ESB2
D516 8-719-991-33 DIODE 1SS133T-77
D517 8-719-951-30 DIODE ERA91-02
D519 8-719-988-61 DIODE 1SS355TE-17
D520 8-719-988-61 DIODE 1SS355TE-17
D522 8-719-988-61 DIODE 1SS355TE-17
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
D706 8-719-979-58 DIODE EGP10D
D707 8-719-109-85 ZENER DIODE RD5.1ESB2
D708 8-719-908-03 DIODE GP08D
D709 8-719-948-45 DIODE ERA22-08
D710 8-719-109-85 ZENER DIODE RD5.1ESB2
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-110-31 ZENER DIODE RD12ESB2
D904 8-719-988-61 DIODE 1SS355TE-17
D905 8-719-110-36 ZENER DIODE RD13ESB2
D906 8-719-063-89 DIODE YG911S3R
D907 8-719-930-97 ZENER DIODE HZS16NB2TD
D908 8-719-018-82 DIODE RGP02-20EL-6394
D909 8-719-930-97 ZENER DIODE HZS16NB2TD
D910 8-719-991-33 DIODE 1SS133T-77
D912 8-719-979-58 DIODE EGP10D
D913 8-719-991-33 DIODE 1SS133T-77
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-929-72 ZENER DIODE HZS33NB2
D917 8-719-988-61 DIODE 1SS355TE-17
D918 8-719-991-33 DIODE 1SS133T-77
D919 8-719-991-33 DIODE 1SS133T-77
D920 8-719-928-85 ZENER DIODE HZS4.7NB2
D921 8-719-988-61 DIODE 1SS355TE-17
D922 8-719-018-82 DIODE RGP02-20EL-6394
D923 8-719-988-61 DIODE 1SS355TE-17
<FERRITE BEAD>
FB501 1-410-397-21 FERRITE 1.1µH
FB502 1-410-397-21 FERRITE 1.1µH
FB503 1-412-911-11 FERRITE 1.1µH
FB504 1-412-911-11 FERRITE 1.1µH
FB505 1-412-911-11 FERRITE 1.1µH
FB506 1-410-397-21 FERRITE 1.1µH
FB507 1-410-397-21 FERRITE 1.1µH
FB901 1-410-397-21 FERRITE 1.1µH
<IC>
IC501 8-759-585-82 IC BA9759F-E2
IC502 8-759-803-42 IC LA6500-FA
IC503 8-759-058-50 IC XRA10324AF
IC701 8-759-444-82 IC LA7841L
IC901 8-759-585-81 IC BA9758FS-E2
<CHIP CONDUCTOR>
JR002 1-216-296-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR004 1-216-295-91 SHORT 0
JR005 1-216-296-91 SHORT 0
JR006 1-216-295-91 SHORT 0
JR008 1-216-295-91 SHORT 0
JR009 1-216-295-91 SHORT 0
JR010 1-216-295-91 SHORT 0
JR011 1-216-295-91 SHORT 0
JR012 1-216-296-91 SHORT 0
JR013 1-216-295-91 SHORT 0
JR014 1-216-296-91 SHORT 0
JR015 1-216-296-91 SHORT 0
JR016 1-216-295-91 SHORT 0
<COIL>
L501 1-412-537-31 INDUCTOR 100µH
L502 1-406-673-11 COIL, CHOKE 2.2mH
L503 1-406-671-11 COIL, CHOKE 1mH
L504 1-406-675-11 COIL, CHOKE 4.7mH
L505 1-416-401-31 COIL, CHOKE 5mH
L901 1-412-537-31 INDUCTOR 100µH
L902 1-406-660-41 COIL, CHOKE 15µH
<TRANSISTOR>
Q501 8-729-048-49 TRANSISTOR 2SK3262-01MR-F119
Q502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q503 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q504 8-729-901-87 TRANSISTOR 2SC2411K-CQ
Q505 8-729-901-97 TRANSISTOR 2SA1036K-Q
Q506 8-729-048-49 TRANSISTOR 2SK3262-01MR-F119
Q507 8-729-048-49 TRANSISTOR 2SK3262-01MR-F119
D
