CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-11
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
<SPARK GAP>
SG901 1-517-499-21 GAP, SPARK
SG902 1-519-422-11 GAP, SPARK
SG903 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 1-435-070-11 TRANSFORMER, HORIZONTAL DRIVE
T502 1-429-301-11 TRANSFORMER, FERRITE (HCT)
T503 1-431-413-21 TRANSFORMER, FERRITE (HST)
T505 1-419-127-11 COIL, HORIZONTAL LINEARITY
T701 1-431-414-11 TRANSFORMER, FERRITE (DFT)
T901 1-416-402-11 INDUCTOR 500µH
T902 ! X-4560-175-1 TRANSFORMER ASSY, FLYBACK
(NX-4502//J1D4)
<THERMISTOR>
TH501 1-807-796-11 THERMISTOR
TH502 1-807-796-11 THERMISTOR
***************************************************************************
* A-1372-770-A H1 BOARD, COMPLETE
[U/C for Mexico-made set]
* A-1372-799-A H1 BOARD, COMPLETE
[U/C for Japan-made set]
* A-1646-206-A H1 BOARD, COMPLETE [AEP]
****************************
<CAPACITOR>
C802 1-126-791-11 ELECT 10µF 20% 16V
C806 1-126-786-11 ELECT 47µF 20% 16V
<CONNECTOR>
CN801*1-564-526-11 PLUG, CONNECTOR 11P
<DIODE>
D801 8-719-064-11 DIODE SPR-325MVW (POWER)
<TRANSISTOR>
Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q803 8-729-029-40 TRANSISTOR DTA124ESA
Q804 8-729-029-40 TRANSISTOR DTA124ESA
<RESISTOR>
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-413-11 CARBON 470 5% 1/4W
R803 1-247-815-91 CARBON 220 5% 1/4W
R804 1-247-815-91 CARBON 220 5% 1/4W
R811 1-249-429-11 CARBON 10K 5% 1/4W
R812 1-249-429-11 CARBON 10K 5% 1/4W
R813 1-247-863-91 CARBON 22K 5% 1/4W
R814 1-249-441-11 CARBON 100K 5% 1/4W
R815 1-215-445-00 METAL 10K 1% 1/4W
R821 1-215-401-11 METAL 150 1% 1/4W
R822 1-215-413-00 METAL 470 1% 1/4W
R823 1-215-421-00 METAL 1K 1% 1/4W
R824 1-215-425-00 METAL 1.5K 1% 1/4W
R851 1-249-413-11 CARBON 470 5% 1/4W
R852 1-247-807-31 CARBON 100 5% 1/4W
R853 1-247-807-31 CARBON 100 5% 1/4W
<SWITCH>
S801 1-771-734-11 SWITCH, TACTILE (MENU)
S812 1-554-303-21 SWITCH, KEY BOARD (RESET)
<THERMISTOR>
TH801 1-807-796-11 THERMISTOR
***************************************************************************
* A-1388-250-B J BOARD, COMPLETE
[U/C for Japan-made set]
* A-1388-260-B J BOARD, COMPLETE [AEP]
* A-1388-261-B J BOARD, COMPLETE
[U/C for Mexico-made set]
**************************
<CONNECTOR>
CN891*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
<SWITCH>
S891 ! 1-571-433-31 SWITCH, PUSH (AC POWER)
***************************************************************************
* A-1394-950-B N BOARD, COMPLETE [AEP]
* A-1394-973-A N BOARD, COMPLETE
[U/C for Mexico-made set]
* A-1394-984-A N BOARD, COMPLETE
[U/C for Japan-made set]
***************************
<CAPACITOR>
C001 1-163-009-11 CERAMIC CHIP0.001µF 10% 50V
C002 1-163-009-11 CERAMIC CHIP0.001µF 10% 50V
D H1 JN
