CPD-E500/E500E
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
7-13
The components identified ! marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
C5304 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C5305 1-104-664-11 ELECT 47µF 20% 25V
C5306 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C5308 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C5310 1-104-664-11 ELECT 47µF 20% 25V
C5401 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C5403 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C5404 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C5406 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C5408 1-163-005-11 CERAMIC CHIP470pF 10% 50V
C5409 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C5413 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C5501 1-126-967-11 ELECT 47µF 20% 50V
C5602 1-115-339-11 CERAMIC CHIP0.1µF 10% 50V
C5606 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C5607 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
<CONNECTOR>
CN001 1-784-500-11 CONNECTOR, FFC/FPC 21P
CN002*1-564-511-11 PLUG, CONNECTOR 8P
CN007*1-564-512-11 PLUG, CONNECTOR 9P
CN010 1-784-786-11 CONNECTOR, FFC 25P
CN011 1-784-786-11 CONNECTOR, FFC 25P
CN5001*1-564-509-11PLUG, CONNECTOR 6P
CN5002*1-564-511-11PLUG, CONNECTOR 8P
CN5003*1-564-505-11PLUG, CONNECTOR 2P
<DIODE>
D001 8-719-062-51 DIODE 1PS226-115
D002 8-719-062-51 DIODE 1PS226-115
D003 8-719-109-89 DIODE 1PS226-115 [AEP]
D004 8-719-109-89 DIODE 1PS226-115 [AEP]
D005 8-719-109-89 ZENER DIODE RD5.6ESB2 [U/C]
D006 8-719-109-89 ZENER DIODE RD5.6ESB2 [U/C]
D007 8-719-109-89 ZENER DIODE RD5.6ESB2 [U/C]
D008 8-719-109-89 ZENER DIODE RD5.6ESB2 [AEP]
D009 8-719-109-89 ZENER DIODE RD5.6ESB2 [AEP]
D010 8-719-109-89 ZENER DIODE RD5.6ESB2 [AEP]
D011 8-719-109-89 ZENER DIODE RD5.6ESB2 [U/C]
D012 8-719-109-89 ZENER DIODE RD5.6ESB2 [AEP]
D013 8-719-110-17 ZENER DIODE RD10ESB2
D014 8-719-066-11 DIODE 1PS184-115 [U/C]
D015 8-719-066-11 DIODE 1PS184-115 [AEP]
D016 8-719-109-89 ZENER DIODE RD5.6ESB2
D017 8-719-109-89 ZENER DIODE RD5.6ESB2
D018 8-719-109-89 ZENER DIODE RD5.6ESB2
D020 8-719-988-61 DIODE 1SS355TE-17
D021 8-719-988-61 DIODE 1SS355TE-17
D022 8-719-066-11 DIODE 1PS184-115
D023 8-719-066-11 DIODE 1PS184-115
D024 8-719-066-11 DIODE 1PS184-115 [AEP]
D025 8-719-062-51 DIODE 1PS226-115
D026 8-719-062-51 DIODE 1PS226-115
D027 8-719-988-61 DIODE 1SS355TE-17
D028 8-719-988-61 DIODE 1SS355TE-17
D029 8-719-109-85 ZENER DIODE RD5.1ESB2
D036 8-719-109-89 ZENER DIODE RD5.6ESB2
D038 8-719-045-99 ZENER DIODE RD2.2M-T1B
D040 8-719-109-89 ZENER DIODE RD5.6ESB2
<FERRITE BEAD>
FB001 1-410-397-21 FERRITE 1.1µH
FB002 1-410-397-21 FERRITE 1.1µH
FB003 1-410-397-21 FERRITE 1.1µH
FB51011-412-911-11 FERRITE 1.1µH
FB51031-412-911-11 FERRITE 1.1µH
FB52011-412-911-11 FERRITE 1.1µH
FB53011-412-911-11 FERRITE 1.1µH
FB53031-412-911-11 FERRITE 1.1µH
FB54011-412-911-11 FERRITE 1.1µH
FB54031-412-911-11 FERRITE 1.1µH
FB56011-412-911-11 FERRITE 1.1µH
<SENSOR>
GS5001 1-418-473-11 SENSOR UNIT, GEOMAGNETIC
<IC>
IC001 8-759-658-88 IC CXD8744Q-0007
IC002 8-759-162-80 IC MM1170BFB
IC003 8-759-527-77 IC M24C16-MN6T
IC004 8-759-639-81 IC SN74AHCT74PWR [AEP]
IC005 8-759-639-81 IC SN74AHCT74PWR
IC006 8-759-700-78 NJM082M
IC010 8-759-585-70 IC LA7865M-TLM
IC011 8-759-442-20 IC 24LC21AT/SN [AEP]
IC012 8-759-442-20 IC 24LC21AT/SN [U/C]
IC5101 8-759-822-07 IC LA6515
IC5201 8-759-822-07 IC LA6515
IC5301 8-759-822-07 IC LA6515
IC5401 8-759-822-07 IC LA6515
<COIL>
L002 1-406-665-11 COIL, CHOKE 100µH
L003 1-406-671-11 COIL, CHOKE 1mH
<TRANSISTOR>
Q001 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q002 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q003 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q004 8-729-028-83 TRANSISTOR DTA124EUA-T106
Q005 8-729-033-26 TRANSISTOR DTA114GKAT146
Q006 8-729-027-49 TRANSISTOR DTC123EKA-T146
Q007 8-729-901-00 TRANSISTOR DTC124EK
Q008 8-729-033-25 TRANSISTOR DTC114GKA
N
