KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
— 43 —
Control Register
Function & Link
Register Name
(Software)
Data
Type
Data
Range
Pro Movie Standard Vivid Pro Movie Standard Vivid
0 POP Selection of service data tables (Table #: 0~15) 0~15 0 1 2 3 4 5 6 7
19 SHLY Y coefficient code of Horizontal LPF (S) s_hlpf_ycoef 0~7 0 0 0 0 0 0 0 0
20 SHLC C coefficient code of Horizontal LPF (S) s_hlpf_ccoef 0~7 0 0 0 0 0 0 0 0
21 SVLY Y coefficient code of Vertical LPF (S) s_vlpf_ycoef 0~7 0 0 0 0 0 0 0 0
22 SVLC C coefficient code of Vertical LPF (S) s_vlpf_ccoef 0~7 0 0 0 0 0 0 0 0
23 SHYR Y coreing code of horizontal enhancement (S) s_henh_ycore 0~3 0 0 0 0 0 0 0 0
24 SHYL Y cliping code of horizontal enhancement (S) s_henh_yclip 0~3 0 0 0 0 0 0 0 0
25 SHYE Y level code of horizontal enhancement (S) s_henh_yenh 0~7 0 0 0 0 0 0 0 0
26 SHYO Y coefficient code of horizontal enhancement (S s_henh_ycof 0, 1 0 0 0 0 0 0 0 0
27 SHCR C coreing code of horizontal enhancement (S) s_henh_ccore 0~3 0 0 0 0 0 0 0 0
28 SHCL C cliping code of horizontal enhancement (S) s_henh_cclip 0~3 0 0 0 0 0 0 0 0
29 SHCE C level code of horizontal enhancement (S) s_henh_cenh 0~7 0 0 0 0 0 0 0 0
30 SHCO C coefficient code of horizontal enhancement (
S
s_henh_ccof 0, 1 0 0 0 0 0 0 0 0
31 SVYR Y coreing code of vertical enhancement (S) s_venh_ycore 0~3 0 0 0 0 0 0 0 0
32 SVYL Y cliping code of vertical enhancement (S) s_venh_yclip 0~3 0 0 0 0 0 0 0 0
33 SVYE Y level code of vertical enhancement (S) s_venh_yenh 0~7 0 0 0 0 0 0 0 0
34 SVCR C coreing code of vertical enhancement (S) s_venh_ccore 0~3 0 0 0 0 0 0 0 0
35 SVCL C cliping code of vertical enhancement (S) s_venh_cclip 0~3 0 0 0 0 0 0 0 0
36 SVCE C level code of vertical enhancement (S) s_venh_cenh 0~7 0 0 0 0 0 0 0 0
Register
No.&Name
DX1A-2001&2000 SERVICE LIST (#13): MID5 (Picture Data: MIDE) (Part-3/4)
Note:
The same MID5 service data is used for DX1A-2001&2000.
YPbPr-480i (DVD)
Data Initial/Average Setting
(32V&36V CRTs)
UHF/VHF & CV
Settings for P&P (Sub)
Data Initial/Average Setting
(32V&36V CRTs)
See
the
next
page.
