KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
— 44 —
Register
No.&Name
Comment
Pro Movie Standard Vivid Pro Movie Standard Vivid
#0 POP
(
cont.
)
8 9 10 11 12 13 14 15
#19 SHLY
(
cont.
)
0000 0000
#20 SHLC
(
cont.
)
0000 0000
#21 SVLY
(
cont.
)
0000 0000
#22 SVLC
(
cont.
)
0000 0000
#23 SHYR
(
cont.
)
0000 0000
#24 SHYL
(
cont.
)
0000 0000
#25 SHYE
(
cont.
)
0000 0000
#26 SHYO
(
cont.
)
0000 0000
#27 SHCR
(
cont.
)
0000 0000
#28 SHCL
(
cont.
)
0000 0000
#29 SHCE
(
cont.
)
0000 0000
#30 SHCO
(
cont.
)
0000 0000
#31 SVYR
(
cont.
)
0000 0000
#32 SVYL
(
cont.
)
0000 0000
#33 SVYE
(
cont.
)
0000 0000
#34 SVCR
(
cont.
)
0000 0000
#35 SVCL
(
cont.
)
0000 0000
#36 SVCE
(
cont.
)
0000 0000
Data Initial/Average Setting
(32V&36V CRTs)
Data Initial/Average Setting
(32V&36V CRTs)
DX1A-2001&2000 SERVICE LIST (#13): MID5 (Picture Data: MIDE) (Part-4/4)
Note:
The same MID5 service data are used for DX1A-2001&2000.
YPbPr-480p YPbPr-1080i
Control Register
Function & Link
Data
Type
Data
Range
Data Initial/Average Setting
(32V&36V CRTs)
Comment
0 HPOS OSD horizontal
p
osition C 0~255 23
C: Common data
1 HPOF Horizontal
p
osition for Favorite mode C 0~255 33
2
V
POS OSD vertical
p
osition C 0~255 5
3
V
POT Vertical
p
osition for P&P
(
Twin
)
mode C 0~255 32
Device Name: M306V2ME-153FP (V1.0) { System Micro (MASK type) / Mitsubishi } / IC701 (A-board)
Slave Address: 60h
System Micro (MASK type): M306V2ME-153FP, Sys-Software: Version 1.0, P/N: 6-800-051-01 (SB#: V9091)
Note:
* This OSD settings are used for DX1A-2001 ONLY. (DX1A-2000 uses two OSD settings based on two versions of system micros.)
Register
No & Name
DX1A-2001* SERVICE LIST (#14): On-Screen Display (OSD)
