Sony TRINITRON KV-32HS20 - Page 45

KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
— 45 —
Control Register
Function & Link
Data
Type
Data
Range
Comment
0 SNN
R
SNNR data settin
g
0~3 0
1 SNFX
Selection of SNNR data settings;
0: Set SNNR automatically according to WSLT value (read
data
)
C 0, 1 0
C: Comon data
2 WSLT Noise level detection data thretholds for SNNR data
(
read data
)
0~255 0~30 31~62 63~126 127~255
SNNR data used as the (-) offset settings
SNNR = 0/1/2/3 @ WSLT £ 0/31/63/127, respectively 0~3 0123
3 CPFG
Related to 3D-COMB
(
mPD64082
)
/ #19
Y
PFG settin
g
s
------ 0123
4 CPFT
Related to 3D-COMB
(
mPD64082
)
/ #18
Y
PFT settin
g
s
------ 0000
SNNR data used as the direct settings
------
5 CCO
R
Related to 3D-COMB
(
mPD64082
)
/ #20
Y
HCO settin
g
s
------ 0111
6 CHCG
Related to 3D-COMB
(
mPD64082
)
/ #21
Y
HCG settin
g
s
------ 1111
SNNR data used as the (-) offset settings
7 CAPG
Related to 3D-COMB
(
mPD64082
)
/ #16
V
APG settin
g
s
------ 0000
8 3SHP
Related to CXA2103 / #6 SHAP settin
g
s
------ 0123
9 MIDD
Related to CXA2150P-3 / #19 MIDE settin
g
s
------ 0123
10 5SHP
Related to CXA2150P-4 / #4 USHP settin
g
s
------ 0134
11 5YF1
Related to CXA2150P-3 / #10 F1LV settin
g
s
------ 0123
12 5CDS
Related to CXA2150P-3 / #11 CDSP settin
g
s
------ 0000
13 5LTI
Related to CXA2150P-3 / #12 LTLV settin
g
s
------ 0000
14 5CTI
Related to CXA2150P-3 / #14 CTLV settin
g
s
------ 0000
15 5VML
Related to CXA2150P-3 / #1 UVML settin
g
s
------ 0000
SNNR data used as the (+) offset settings
16 5VMC
Related to CXA2150P-3 / #3
V
MCR settin
g
s
------ 0 + 1 + 2 + 3
Note:
The same SNNR service data is used for DX1A-2001&2000.
Please refer to the part numbers and SBorSD numbers given in the service list for these devices.
DX1A-2001&2000 SERVICE LIST (#15): SNNR
Related Control Devices:
mPD64082 { 3D-Comb / NEC } / IC3501 (BC-board) / Slave Address: B8h
CXA2103Q { Chroma Decoder / SONY } / IC3048 (B-board) / Slave Address: 9Ah (Main)
CXA2150Q { CRT Driver / SONY } / IC201 (A-board) / Slave Address: 86h
Register
No & Name
SNNR Settings Based on WSL Dat
a
( - Offset Data)
SNNR Settings Based on WSL Dat
a
( + Offset Data)
WSLT Data / Threthold Range
Data Initial/Average Setting
32V&36V CRTs
