Control Register
Function & Link
Data
Type
Data
Range
Data Initial/Average Setting
(32V&36V CRTs)
Comment
0
XJGL
XJGLK: Setting for memorizing or not the ID-1 detection
status
C 0, 1 0
1 LNJI LNJ1: Settin
g
for the multi/sin
g
le-line ID-1 detection C 0, 1 0
DX1A-2001&2000 SERVICE LIST (#16): ID-1 Detection (ID1)
Device Name: CXD2085M { ID-1 Decoder / SONY } / IC3603 (B-board) / P/N: 8-752-395-13 (SD#: S98511B)
Slave Address: 40h
Note:
The same ID1 service data are used for DX1A-2001&2000.
Other servcie controls related to CXD2085 (IDSW & DATA) are lised in Service List (CXA2150P-4) for easier engineering adjustment.
C
: Common data
Register
No & Name
Control Register
Function & Link
Data
Type
Data
Range
Data Initial/Average Setting
(32V&36V CRTs)
Comment
0 HPRM Horizontal
p
osition of CCD
(
Main
)
C 0~255 46
C: Common data
1 HPRS Horizontal
p
osition of CCD
(
Sub
)
C 0~255 46
2 RND OSD roundin
g
control C 0, 1 1
3 CCDI Interu
p
tion cointrol C 0~7 3
4 CRIP CRI count &
p
arit
y
count C 0~7 4
5 CRIT Char
g
e/Dischar
g
e timin
g
control for slice volta
g
e level C 0, 1 0
0: MASK-type micro, 1: OTP-type micro
6 CHMK Horizontal mask width C 0~63 42
7 FPOL Field
p
olarit
y
selection C 0, 1 1
8 LANG C 0~3 0
9 DAT
A
Switch for CCD service/test data C 0, 1 0
10
V
CHIP Selection of Vchi
p
controls C 0, 1 0
Note:
The same CCD&VCHIP service data is used for DX1A-2001&2000.
Register
No & Name
Device Name: CXP85840A-039Q { CCD&Vchip Micro (MASK type) / SONY } / IC3602 (Main) & IC3601 (Sub) (B-board) / P/N: 8-752-916-40 (SD#: S97739B)
Slave Address: 68h (Main) & 6Ch (Sub)
CCD&Vchip Micro Software: Version 2.14
DX1A-2001&2000 SERVICE LIST (#17): Closed Caption Display & Parental Control (CCD&VCHIP
)
