Sony TRINITRON KV-32HS20 - Page 47

KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
— 47 —
Control Register
Function & Link
Data
Type
Data
Range
Data Initial/Average Setting
(32V&36V CRTs)
Comment
0 DLY1 AC-RLY to MAIN-RLY timin
g
= DLY1 x 50 ms C 0~15 4
C: Common data
1 DLY2 Power-On Mute timin
g
= DLY2 x 50 ms C 0~31 12
2 DLY3 DGC-RLY to MAIN-RLY timin
g
= DLY3 x 50 ms C 0~15 7
3 RAM
W
RAM monitor on/off C 0, 1 0
Note:
The same OP service data is used for DX1A-2001&2000.
DX1A-2001&2000 SERVICE LIST (#18): OPTIONS (OP)
Register
No & Name
System Micro (MASK type): M306V2ME-153FP, Sys-Software: Version 1.0, P/N: 6-800-051-01 (SB#: V9091)
Device Name: M306V2ME-153FP (V1.0) { System Micro (MASK type) / Mitsubishi } / IC701 (A-board)
Slave Address: 60h
Control Register
Function & Link
Data
Type
Data
Range
Comment
Shipping Destination-related Settings
KV-32HS20
KV-36HS20
KV-32HS20H
KV-32XBR450
KV-36XBR450
KV-36XBR450H
KV-32XBR450C
KV-36XBR450C
0 ID0 Selection of OSD lan
g
ua
g
es & color s
y
stems 0~255 89 89 89
1 ID1 Selection of com
p
osite & s-video in
p
uts 0~255 127 127 127
2 ID2 Selection of audio-related controls 0~255 239 255 255
3 ID3 Selection of basic s
y
stem settin
g
s 0~255 98 106 90
4 ID4 Selection of basic s
y
stem settin
g
s 0~255 203 203 203
5 ID5 Selection of advanced s
y
stem settin
g
s 0~255 177 177 177
6 ID6 Selection of sub
p
icture-related settin
g
s 0~255 54 54 54
7 ID7 Selection of some reserved settin
g
s 0~255 24 24 24
Note:
* These ID settings are used for DX1A-2001 ONLY. (DX1A-2000 uses different ID settings.)
The system micro name, software&patch versions, and the status of NVM devices are displayed only when in this service catergory (#19): ID.
DX1A-2001* SERVICE LIST (#19): IDENTIFICATION (ID)
Device Name: M306V2ME-153FP (V1.0) { System Micro (MASK type) / Mitsubishi } / IC701 (A-board)
Slave Address: 60h
System Micro (MASK type): M306V2ME-153FP, Sys-Software: Version 1.0, P/N: 6-800-051-01 (SB#: V9091)
Data Initial/Average Setting
(32V/36V/40V CRTs)
Register
No & Name
