— 58 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
A BOARD IC VOLTAGE LIST (1 OF 3)
14 2.3 29 5.0 44 GND 59 1.7
pin volt 15 3.7 30 5.6 45 2.8 60 1.7
1 GND 16 2.7 31 1.3 46 3.6 61 9.0
2 0.0 17 2.6 32 3.0 47 3.9 62 2.3
3 GND 18 1.1 33 1.6 48 4.4 63 2.5
4 3.1 19 4.9 34 0.0 49 5.4 64 2.3
5 3.1 20 3.6 35 0.0 50 3.5
6 3.1 21 3.4 36 0.2 51 3.8
7 0.0 22 3.4 37 0.0 52 3.4
8 3.6 23 GND 38 3.2 53 3.5
9 3.6 24 N/C 39 1.1 54 1.0
10 3.6 25 4.6 40 2.8 55 9.0
11 0.0 26 4.6 41 GND 56 1.0
12 0.5 27 0.7 42 0.0 57 4.3
13 0.5 28 0.0 43 3.8 58 3.9
IC201
All voltages are in V.
BCE
Q001 0.4 0.0 GND
Q002 0.4 0.0 GND
Q004 4.6 1.1 5.0
Q005 4.3 9.0 3.6
QO12 0.1 7.5 GND
Q015 6.2 9.0 5.5
Q027 4.5 0.0 5.0
Q203 2.3 GND 3.2
Q204 2.5 GND 3.2
Q205 2.3 3.4 GND
Q206 3.4 4.1 3.5
Q207 2.3 GND 3.2
Q208 2.3 GND 3.2
Q209 0.8 2.2 GND
Q211 2.8 11.5 2.3
Q212 5.6 9.0 5.0
Q214 0.0 0.0 GND
Q216 4.5 GND 3.9
Q217 4.4 8.7 3.9
All voltages are in V.
A BOARD TRANSISTOR
VOLTAGE LIST (1 OF 3)
