KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
A BOARD IC VOLTAGE LIST (2 OF 3)
A BOARD TRANSISTOR
VOLTAGE LIST (2 OF 3)
17 0.0 35 N/C 53 3.0 71 N/C 89 0.0 5 4.9
pin volt 18 0.0 36 0.0 54 0.0 72 6.3 90 0.0
1 N/C 19 0.0 37 4.6 55 0.0 73 0.0 91 0.0 pin volt
2 N/C 20 2.8 38 0.0 56 0.0 74 0.0 92 0.0 1 GND
3 0.0 21 0.0 39 0.0 57 N/C 75 GND 93 0.0 2 GND
4 0.0 22 0.0 40 0.0 58 0.0 76 0.0 94 4.6 3 GND
5 0.0 23 0.0 41 2.3 59 0.0 77 0.0 95 4.6 4 GND
6 0.0 24 GND 42 0.0 60 0.0 78 0.0 96 GND 5 4.6
7 4.7 25 0.0 43 4.6 61 0.0 79 0.0 97 4.6 6 4.6
8 GND 26 N/C 44 2.8 62 4.9 80 N/C 98 GND 7 5.0
9 GND 27 N/C 45 0.1 63 4.9 81 0.0 99 4.9 8 5.0
10 N/C 28 4.4 46 0.0 64 GND 82 0.0 100 4.6
11 N/C 29 4.9 47 4.6 65 0.0 83 0.0
12 4.9 30 4.9 48 5.0 66 N/C 84 0.0 pin volt
13 2.3 31 4.4 49 5.0 67 0.0 85 0.0 1 N/C
14 GND 32 0.0 50 0.0 68 0.0 86 N/C 2 GND
15 2.4 33 0.0 51 5.0 69 7.3 87 0.0 3 GND
16 4.9 34 0.0 52 0.0 70 0.0 88 0.0 4 4.9
IC701
IC702
IC707
All voltages are in V.
BCE
Q701 4.7 4.7 5.0
Q702 0.1 5.0 0.0
Q703 4.6 5.0 GND
Q704 0.0 4.4 GND
Q705 5.0 0.0 0.0
Q706 5.0 0.0 0.0
Q707 0.5 0.0 GND
Q709 10.4 0.7 10.2
Q710 19.5 0.0 19.9
Q712 0.0 5.0 0.0
Q717 0.0 5.0 GND
Q719 0.6 4.5 GND
Q720 4.5 0.0 4.5
Q721 0.0 0.0 GND
Q723 0.2 4.6 GND
Q724 0.5 4.6 GND
Q731 0.0 0.0 5.0
All voltages are in V.
