Sony TRINITRON KV-32WS4A - Disassembly; Rear Cover Removal; Speaker Removal; Chassis Assy Removal

KV-32WS4
— 17 —
SECTION 2
DISASSEMBLY
2-1. REAR COVER REMOVAL
2-2. SPEAKER REMOVAL
2-3. CHASSIS ASSY REMOVAL
2-4. SERIVCE POSITION
2-5. G BOARD REMOVAL
Push the claw of the bracket
in the direction of the arrow
and remove.
Rear Cover
2
1
Five screws
(BVTP 4x16)
