Sony TRINITRON KV-32WS4A - Block Diagram (6)

2
2.0 Vp-p (H) 1.0 Vp-p (H)
3
1.0 Vp-p (H)
1
1.0 Vp-p (H)
1
WAVEFORMS A BOARD
0.6 Vp-p (H)
4
0.7 Vp-p (H)
5
2.0 Vp-p (H)
2
1.2 Vp-p (H)
3
4.5 Vp-p (H)
6
1.5 Vp-p (H) 1.0 Vp-p (H)
11
1.0 Vp-p (H)
7
1.0 Vp-p (H)
8
1.4 Vp-p (H)
9
PAL SECAM PAL
SECAM PAL SECAM
10
4
107 Vp-p (2H) 95 Vp-p (2H)
5
2.0 Vp-p (2H)
1
2.0 Vp-p (2H)
2
WAVEFORMS C BOARD
30 Vp-p (2H)
7
2.0 Vp-p (2H)
3
100 Vp-p (2H)
6
