DEFLECTION SYSTEM ADJUSTMENT
1. Enter into the service mode and select 'Deflect cont.'.The
'Deflect cont. SDA9361' adjustment menu will be displayed.
2. Select and adjust each item in order to get an optimum image.
V SIZE
V POS
V LIN
H SIZE
H PIN CUSH
H TILT
H UP COR
H LOWER COR
AFC V BOW
AFC V ANGLE
H POS
