REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
— 114 —
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
KV-32WS4
B
C1849 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C1850 1-163-107-00 CERAMIC CHIP 39PF 5% 50V
C1852 1-164-005-11 CERAMIC CHIP 0.47MF 16V
C1853 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C1854 1-164-005-11 CERAMIC CHIP 0.47MF 16V
C1855 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C1856 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C1857 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C1858 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C1859 1-164-005-11 CERAMIC CHIP 0.47MF 16V
C1860 1-126-961-11 ELECT 2.2MF 20% 50V
C1861 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C1862 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C1864 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C1865 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1866 1-126-964-11 ELECT 10MF 20% 50V
C1867 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1868 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1869 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1870 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1871 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1872 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1873 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1874 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1875 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1876 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C1877 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C1878 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1879 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1880 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1881 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1882 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1883 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1884 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1885 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1886 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1887 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1889 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1890 1-126-964-11 ELECT 10MF 20% 50V
C1891 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1892 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1893 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1894 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1898 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1899 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C1903 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1904 1-163-145-00 CERAMIC CHIP 0.0015MF 5% 50V
C1910 1-126-964-11 ELECT 10MF 20% 50V
C1912 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1919 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1921 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C1922 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C1924 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1925 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1926 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1927 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1928 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1931 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1932 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C1933 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C1935 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C1947 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1948 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
JR426 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
R1824 1-164-049-11 CERAMIC 13PF 5% 50V
R1839 1-126-963-11 ELECT 4.7MF 20% 50V
< CONNECTOR >
CN412 *1-564-513-11 PLUG, CONNECTOR 10P
CN413 *1-564-511-11 PLUG, CONNECTOR 8P
CN417 *1-564-596-11 PLUG, CONNECTOR 15P
CN419 *1-564-512-11 PLUG, CONNECTOR 9P
CN1810 *1-564-512-11 PLUG, CONNECTOR 9P
CN1813 1-778-822-11 CONNECTOR BOARD TO BOARD 40P
(KV-32WS4A/32WS4D/32WS4E/32WS4K/32WS4R/
32WS4U)
CN1815 *1-564-512-11 PLUG, CONNECTOR 9P
< DIODE >
D401 8-719-914-43 DIODE DAN202K
D402 8-719-914-43 DIODE DAN202K
D403 8-719-028-00 DIODE MA3033-L
D410 8-719-401-63 DIODE MA3062M-TX
D411 8-719-914-43 DIODE DAN202K
D412 8-719-914-43 DIODE DAN202K
D414 8-719-914-42 DIODE DA204K
D415 8-719-914-43 DIODE DAN202K
< FERRITE BEAD >
FB401 1-414-234-11 INDUCTOR, FERRITE BEAD
FB402 1-414-234-11 INDUCTOR, FERRITE BEAD
FB403 1-414-234-11 INDUCTOR, FERRITE BEAD
FB404 1-414-234-11 INDUCTOR, FERRITE BEAD
FB405 1-414-234-11 INDUCTOR, FERRITE BEAD
FB406 1-414-234-11 INDUCTOR, FERRITE BEAD
FB407 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1801 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1802 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1803 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1804 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1805 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1806 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1807 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1808 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1809 1-414-234-11 INDUCTOR, FERRITE BEAD
FB1810 1-414-234-11 INDUCTOR, FERRITE BEAD
< ENCAPSULATED FILTER >
FL1801 1-233-767-11 FILTER
FL1803 1-415-940-11 DELAY LINE
FL1807 1-236-071-11 ENCAPSULATED COMPONENT
FL1808 1-236-071-11 ENCAPSULATED COMPONENT
FL1809 1-236-071-11 ENCAPSULATED COMPONENT
< IC >
IC402 8-759-275-36 IC TDA4780/V3
IC403 8-759-421-42 IC SDA9361
IC405 8-759-438-33 IC 74LVC08D
IC406 8-759-439-64 IC HEF4053BT
IC1801 8-759-257-59 IC TDA8755T-T
