REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
KV-32WS4
— 129 —
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
D
D1603 8-719-911-19 DIODE 1SS119-25
D1604 8-719-970-87 DIODE ERA38-06
D1605 8-719-970-87 DIODE ERA38-06
D1609 8-719-979-85 DIODE EGP20G
D1612 8-719-110-08 DIODE RD8.2ES-B2
D2701 8-719-911-19 DIODE 1SS119-25
D2702 8-719-911-19 DIODE 1SS119-25
< CONNECTOR >
DY1 *1-580-798-11 CONNECTOR PIN (DY) 6P
< FUSE >
F601 1-532-505-41 FUSE 5A/250V
*1-533-725-11 HOLDER, FUSE ; F601
< FERRITE BEAD >
FB801 1-410-396-41 FERRITE BEAD INDUCTOR 0.45UH
< IC >
IC236 8-759-190-89 IC TDA7265
4-202-373-01 SPRING, IC ; IC236
4-202-710-01 SPACER, INSULATING ; IC236
IC260 8-759-330-93 IC TDA7309
IC261 8-759-502-21 IC TDA2822M
IC603 8-759-095-34 IC LM2940T-8.0
4-382-854-11 SCREW (M3X10), P, SW (+) ; IC603
IC604 8-759-513-71 IC PQ05RF21
4-202-373-01 SPRING, IC ; IC604
IC606 8-759-991-43 IC LM78L12ACZ
IC607 8-759-513-71 IC PQ05RF21
4-202-373-01 SPRING, IC ; IC607
IC801 8-759-103-93 IC UPC393C
IC802 8-759-192-71 IC STV9379
4-202-373-01 SPRING, IC ; IC802
IC1601 8-759-103-93 IC UPC393C
IC1603 8-759-103-93 IC UPC393C
IC2701 8-759-603-37 IC M5216P
< SOCKET >
J1200 1-770-218-11 JACK, PIN
< COIL >
L602 1-412-525-31 INDUCTOR 10UH
L603 1-412-525-31 INDUCTOR 10UH
L802 1-459-474-11 COIL (WITH CORE)
L803 1-459-474-11 COIL (WITH CORE)
L806 1-459-592-11 COIL (WITH CORE) (PMC)
L807 1-412-524-11 INDUCTOR 8.2UH
L811 1-459-104-00 COIL, WITH CORE
L814 1-422-613-11 COIL, AIR CORE
L815 1-410-397-21 FERRITE BEAD INDUCTOR 1.1UH
L816 1-408-947-00 INDUCTOR 2.2MMH
L1602 1-459-474-11 COIL (WITH CORE)
L1605 1-459-104-00 COIL (WITH CORE)
L1622 1-406-675-11 COIL, CHOKE 4.7MMH
< IC LINK >
PS1601 1-532-637-91 LINK, IC 1A (ICP-N25)
< TRANSISTOR >
Q276 8-729-030-03 TRANSISTOR DTC144ESA-TP
Q277 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q278 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q279 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q280 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q281 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q282 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q606 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q607 8-729-029-56 TRANSISTOR DTA144ESA
Q613 8-729-030-03 TRANSISTOR DTC144ESA-TP
Q614 8-729-029-56 TRANSISTOR DTA144ESA
Q616 8-729-030-03 TRANSISTOR DTC144ESA-TP
Q617 8-729-029-67 TRANSISTOR DTC114ESA-TP
Q618 8-729-029-56 TRANSISTOR DTA144ESA
Q620 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q624 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q801 8-729-119-80 TRANSISTOR 2SC2688-LK
Q802 8-729-821-07 TRANSISTOR 2SC3997CA
4-200-399-01 SPACER, IC ; Q802
4-382-854-11 SCREW (M3X10), P, SW (+) ; Q802
Q803 8-729-039-68 TRANSISTOR IRF620
4-200-399-01 SPACER, IC ; Q803
Q804 8-729-039-68 TRANSISTOR IRF620
Q1601 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1602 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1603 8-729-011-06 TRANSISTOR 2SC3840K
Q1610 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1611 8-729-931-45 TRANSISTOR IRF614
Q2701 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R236 1-249-424-11 CARBON 3.9K 5% 1/4W
R237 1-249-417-11 CARBON 1K 5% 1/4W
R239 1-249-424-11 CARBON 3.9K 5% 1/4W
R240 1-249-417-11 CARBON 1K 5% 1/4W
R244 1-249-413-11 CARBON 470 5% 1/4W
R245 1-249-430-11 CARBON 12K 5% 1/4W
R246 1-249-430-11 CARBON 12K 5% 1/4W
R247 1-249-413-11 CARBON 470 5% 1/4W
R248 1-249-425-11 CARBON 4.7K 5% 1/4W
R249 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R250 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R251 1-249-429-11 CARBON 10K 5% 1/4W
R252 1-249-429-11 CARBON 10K 5% 1/4W
R255 1-249-411-11 CARBON 330 5% 1/4W
R256 1-249-411-11 CARBON 330 5% 1/4W
R260 1-247-863-91 CARBON 22K 5% 1/4W
R261 1-247-863-91 CARBON 22K 5% 1/4W
R262 1-249-421-11 CARBON 2.2K 5% 1/4W
R263 1-249-421-11 CARBON 2.2K 5% 1/4W
R264 1-212-857-00 FUSIBLE 10 5% 1/4W F
R265 1-249-389-11 CARBON 4.7 5% 1/4W F
R266 1-249-389-11 CARBON 4.7 5% 1/4W F
R267 1-247-815-91 CARBON 220 5% 1/4W
R268 1-247-815-91 CARBON 220 5% 1/4W
R269 1-249-415-11 CARBON 680 5% 1/4W
R270 1-249-415-11 CARBON 680 5% 1/4W
R271 1-247-742-11 CARBON 180 5% 1/2W F
R277 1-249-419-11 CARBON 1.5K 5% 1/4W
