REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
KV-32WS4
— 135 —
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
R5053 1-216-041-00 METAL GLAZE 470 5% 1/10W
R5054 1-216-041-00 METAL GLAZE 470 5% 1/10W
R5055 1-216-025-91 METAL GLAZE 100 5% 1/10W
R5056 1-216-051-00 METAL GLAZE 1.2K 5% 1/10W
(KV-32WS4B)
R5057 1-216-025-91 METAL GLAZE 100 5% 1/10W
(KV-32WS4B)
R5058 1-216-033-00 METAL GLAZE 220 5% 1/10W
R5059 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R5060 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W
R5061 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
R5062 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W
R5063 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
< TUNER >
TU5001 1-693-338-21 TUNER (TUVIF) (AEP)
(KV-32WS4A/32WS4D/32WS4E/32WS4K/32WS4R)
1-693-340-21 TUNER (TUVIF) (FR) (KV-32WS4B)
1-693-339-21 TUNER (TUVIF) (UK) (KV-32WS4U)
**************************************************************
T
MISCELLANEOUS
*************
1-251-317-31 CAP ASSY, HIGH-VOLTAGE
1-411-871-11 COIL, DEGAUSSING
1-452-032-00 MAGNET, DISK; 10MM Ø
1-452-094-00 MAGNET, ROTATABLE DISK; 15MM Ø
1-452-724-22 COIL, NA ROTATION (RT-165)
1-453-223-11 TRANSFORMER ASSY, FLYBACK
(NX-4123/U2B4)
1-504-418-21 SPEAKER (5CM)
1-505-154-11 SPEAKER (6.5CM)
1-505-155-11 SPEAKER (10CM)
1-571-433-21 SWITCH, PUSH (AC POWER)
1-693-338-21 TUNER (TUVIF) (AEP)
(KV-32WS4A/32WS4D/32WS4E/32WS4K/32WS4R)
1-693-340-21 TUNER (TUVIF) (FR) (KV-32WS4B)
1-693-339-21 TUNER (TUVIF) (UK) (KV-32WS4U)
1-751-680-11 CORD, POWER (WITH NOISE FILTER)
2.5A/250V (KV-32WS4A/32WS4B/32WS4D/
32WS4E/32WS4K/32WS4R)
1-767-204-11 CORD, POWER (FILTER)
3A/250V (KV-32WS4U)
8-451-485-11 DEFLECTION YOKE (Y32C2C2-M)
8-453-011-11 NECK ASSY, (NA299-M)
V901 8-735-032-05 PICTURE TUBE (SD-297)(W76LHT010X)
*************************************************************
ACCESSORIES AND PACKING MATERIALS
*********************************
1-765-654-11 CABLE, SPEAKER
*4-046-772-01 BAG, PROTECTION
*4-050-160-01 CUSHION (UPPER) (ASSY)
*4-050-163-11 CUSHION (LOWER) (ASSY)
*4-050-158-01 INDIVIDUAL CARTON
*4-203-159-01 TRAY (A)
*4-203-166-01 CUSHION (REAR)
*4-203-186-01 WOODEN PALETT
4-203-585-41 MANUAL, INSTRUCTION (KV-32WS4A)
(ITALIAN)
4-203-585-51 MANUAL, INSTRUCTION (KV-32WS4B)
(FRENCH)
4-203-585-11 MANUAL, INSTRUCTION (KV-32WS4D)
(GERMAN/ENGLISH/DUTCH/FRENCH/ITALIAN/
GREEK/TURKISH)
4-203-585-71 MANUAL, INSTRUCTION (KV-32WS4E)
(PORTUGUESE/DANISH/SWEDISH/NORWEGIAN/
FINNISH/SPANISH/FRENCH/DUTCH/GERMAN)
4-203-585-91 MANUAL, INSTRUCTION (KV-32WS4K/32WS4R)
(xxxxx)
4-203-585-61 MANUAL, INSTRUCTION (KV-32WS4U)
(ENGLISH)
*4-396-077-01 JOINT
REMOTE COMMANDER
****************
1-473-692-11 COMMANDER, STANDARD TYPE (RM-862)
**************************************************************
