Sony TRINITRON KV-AR34M3 - Page 73

– 86 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
C6 BOARD VOLTAGE LIST AND WAVEFORM
KB 155
135Vp-p
PA L
3
133Vp-p
3
NTSC3.58
H1 0.3
22.4Vp-p
4
G2 284
Q701 B 154
C 206
E 157
Q702 B 151
C 206
E 151
Q703 B 151
C 206
E 153
Q704 B 8.9
C 154
E 8.3
Ref Pin No. Voltage[v]
IC1800 1 6.5
2 6.5
3 6.5
4 6.4
50
6 6.4
7 6.4
8 6.4
9 6.4
10 12.6
J701 KR 153
122Vp-p
PA L
1
127Vp-p
1
NTSC3.58
KG 148
127Vp-p
PA L
2
125Vp-p
2
NTSC3.58
Ref Pin No. Voltage[v]
Q705 B 8.9
C 153
E 8.3
Q706 B 8.9
C 152
E 8.3
Q707 B 115
C 5.4
E 156
Q708 B (151)[146]
C 6.0
E 150
Q709 B 154
C 5.4
E 154
Q710 B 1.6
C 8.3
E 1.3
Q711 B 1.8
C 8.2
E 1.4
Q712 B 1.6
C 8.3
E 1.3
Q714 B 0.7
C 0.1
E0
Q1800 B 3.8
C0
E 4.5
Q1802 B 0.4
C 3.4
E0
Q1803 B 0
C 6.5
E0
VM1 BOARD VOLTAGE LIST
Ref Pin No. Voltage[v]
Q5901 B 2.7
C 8.8
E 2.0
Q5902 B 0.7
C 0.4
E 0.7
Q5903 B 2.7
C 4.6
E 2.0
Q5904 B 4.6
C0
E 5.1
Q5905 B 5.6
C 8.8
E 5.1
Ref Pin No. Voltage[v]
Q5906 B 0
C 0.3
E0
Q5907 B 0.1
C 0.7
E0
Q5908 B 3.8
C0
E0
Q5909 B 0
C 8.8
E 3.8
Ref Pin No. Voltage[v]
VM1 BOARD
Ref Pin No. Voltage[v]
Q5901 B 2.6
C 8.8
E (0)[2.0]
Q5902 B 135
C 135
E (70)[64]
Q5903 B 2.6
C 4.5
E 1.9
Ref Pin No. Voltage[v]
Q5904 B 4.5
C0
E 5.0
Q5905 B 5.5
C 8.8
E 5.0
Q5906 B (0.27)[0.22]
C (0)[64.7]
E0
Ref Pin No. Voltage[v]
Q5907 B 0
C0
E0
Q5908 B 3.3
C0
E0
Q5909 B 0
C 8.8
E 3.3
