Sony TRINITRON KV-AR34M3 - Page 74

– 87 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
Ref Pin No. Voltage[v]
IC4102 1 0.9
20
3 1.3
40
5 4.9
6 4.9
7 1.3
80
9 0.7
10 (3.5)[0]
11 (0)[4.9]
12 1.5
13 0
14 1.5
15 0
16 1.5
IC4103 1 1.4
2 1.5
3 0.3
4 0.1
5 4.4
6 4.5
7 (3.2)[0]
80
90
10 (1.2)[0.7]
11 (0.1)[0]
12 0
13 0
14 0
15 0
16 0.7
17 0.3
18 0.7
19 3.2
20 0
21 3.2
22 (0)[3.1]
23 0
24 1.6
25 1.1
26 1.6
27 2.0
28 1.3
IC4104 1 (1.9)[0]
2 1.9
3 (1.3)[0]
4 (0.1)[0]
5 2.0
6 4.9
7 2.5
80
9 0.3
10 0.8
11 2.2
12 4.9
13 4.5
14 4.4
15 0
16 0
17 2.4
18 2.4
19 1.3
20 2.3
21 1.6
22 1.8
23 1.8
24 0
25 (1.6)[1.9]
26 (1.5)[1.9]
27 (1.5)[1.9]
28 0
29 2.4
30 2.4
31 1.6
32 4.9
33 (1.5)[1.9]
34 (1.7)[2.1]
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
P5 BOARD VOLTAGE LIST (EXCEPT KV-AR34M60)
35 (1.7)[2.1]
36 0
37 1.0
38 (*)[3.8]
39 (1.6)[1.0]
40 3.4
41 2.2
42 2.4
43 1.7
44 2.2
45 (3.6)[0]
46 (2.2)[3.0]
47 3.7
48 1.7
IC4105 1 4.9
2 (0)[0.3]
30
4 (0)[0.3]
5 4.9
IC4106 I 7.7
G0
O 5.0
IC4201 I 4.9
G0
O 3.3
IC4202 1 0
20
30
4 3.3
5 3.3
IC4203 1 3.3
2 1.6
3 3.3
40
5 3.3
6 3.3
70
8 (1.0)[0.7]
90
10 0.2
11 1.3
12 2.4
13 3.2
14 0
15 0.2
16 0
17 1.3
18 1.3
19 2.4
20 3.2
21 0
22 0.2
23 0
24 1.3
25 1.3
26 2.4
27 3.2
28 0
29 0.3
30 0
31 0
32 3.3
33 0
34 3.3
35 0
36 3.3
37 3.3
38 3.3
39 3.3
40 3.2
41 3.3
42 3.3
43 3.3
44 3.3
45 0
46 3.3
47 3.3
48 3.3
49 3.3
50 3.3
51 3.3
52 3.3
53 3.3
54 3.3
55 0
56 1.9
57 1.5
58 (2.0)[1.3]
59 (1.6)[2.2]
60 1.2
61 (1.1)[0.7]
62 2.4
63 (1.2)[1.5]
64 (1.5)[1.8]
65 1.7
66 0
67 2.0
68 (1.1)[1.6]
69 0.7
70 (1.1)[1.6]
71 (1.0)[1.5]
72 2.3
73 3.3
74 0
75 0
76 1.7
77 0.2
78 0.1
79 1.8
80 0
81 0
82 3.2
83 0.1
84 0
85 0
86 3.2
87 0.1
88 0
89 0
90 3.2
91 3.2
92 0.3
93 0
94 0.1
95 1.0
96 1.0
97 3.3
98 3.3
99 0
100 2.7
101 2.6
102 2.6
103 0
104 0
105 2.4
106 0
107 0
108 0.1
109 0
110 0
112 0
113 0
114 0
115 2.6
116 2.6
117 0
118 3.3
119 3.3
120 0
121 0.3
122 0.3
123 (0.8)[0.5]
124 0
125 3.3
126 3.3
