Sony TRINITRON KV-AR34M3 - Page 75

– 88 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
Ref Pin No. Voltage[v] Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
P5 BOARD VOLTAGE LIST (EXCEPT KV-AR34M60)
127 0
128 1.4
129 1.5
130 0
131 3.3
132 0
133 3.3
134 3.3
135 3.3
136 3.3
137 3.3
138 0
139 0.8
140 0
141 0
142 3.0
143 2.9
144 0
IC4204 1 3.3
20
3 1.4
4 (0)[0.3]
5 1.7
6 1.6
70
80
90
10 0
11 0
12 1.6
13 2.1
14 3.3
IC4301 1 3.3
20
30
40
50
60
70
80
90
10 0
11 0
12 0
13 3.3
14 2.4
15 (1.0)[0.4]
16 3.3
17 3.3
18 0
19 0
20 0
21 (1.7)[2.0]
22 (1.9)[1.3]
23 0
24 3.3
25 (1.9)[1.2]
26 (1.7)[2.2]
27 1.1
28 (1.0)[0.8]
29 2.4
30 (1.2)[1.4]
31 (1.0)[1.4]
32 (1.5)[1.7]
33 3.3
34 0
35 (2.1)[0]
36 (1.1)[1.6]
37 (0.6)[1.6]
38 (1.0)[1.6]
39 1.8
40 (2.3)[1.6]
41 3.3
42 0
43 0.1
44 (3.3)[0]
45 1.6
46 0
47 3.3
48 0
49 3.3
50 3.3
51 3.3
52 0
53 3.3
54 3.3
55 (3.3)[0]
56 0.1
57 0.2
58 1.6
59 0
60 3.3
61 3.3
62 3.3
63 0
64 (2.2)[1.6]
65 (1.0)[1.5]
66 (1.0)[1.6]
67 (0.4)[1.6]
68 (1.1)[1.6]
69 2.0
70 1.7
71 1.4
72 1.4
73 3.3
74 2.4
75 (1.1)[0.8]
76 (1.1)[1.2]
77 (1.5)[2.2]
78 (1.9)[1.3]
79 (1.8)[1.3]
80 (1.8)[2.0]
IC4401 I 3.3
G0
O 1.8
IC4402 1 1.7
2 3.0
3 (3.0)[2.9]
4 3.3
5 3.3
6 1.7
7 0.2
80
90
10 1.5
11 1.9
12 1.2
13 1.5
14 (1.2)[1.6]
15 (2.0)[1.0]
16 1.4
17 1.6
18 3.3
19 0
20 1.2
21 1.2
22 1.7
23 1.4
24 1.4
25 1.1
26 1.6
27 1.6
28 1.3
29 1.3
30 0
31 1.4
32 1.3
33 1.7
34 3.3
35 1.6
36 0
37 *
38 *
39 *
40 *
41 *
42 *
43 *
44 *
45 *
46 *
47 *
48 *
49 *
50 *
51 *
52 *
53 *
54 *
55 *
56 *
57 *
58 *
59 *
60 *
61 *
62 *
63 *
64 *
65 *
66 *
67 *
68 *
69 *
70 *
71 *
72 3.3
73 1.7
74 3.3
75 0
76 0
77 1.8
78 0
79 0.5
80 0
81 0
82 0
83 0
84 3.3
85 (0.8)[0.9]
86 0
87 1.7
88 1.7
89 0
90 3.3
91 0
92 0
93 0.6
94 0
95 1.7
96 0
97 0
98 3.3
99 3.3
100 0
101 3.3
102 0
103 0.3
104 0
105 3.3
106 0
107 0.1
108 0
109 1.7
110 3.3
111 0
112 0
113 1.6
114 3.3
115 0.2
116 1.7
117 0
118 3.3
119 1.1
