Sony TRINITRON KV-AR34M3 - Page 76

– 89 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
Ref Pin No. Voltage[v]
120 2.2
121 1.9
122 2.2
123 2.0
124 2.1
125 1.8
126 3.3
127 0
128 1.4
129 1.3
130 2.4
131 1.0
132 1.1
133 1.5
134 2.1
135 2.4
136 1.6
137 1.7
138 0
139 0
140 0
141 0
142 0
143 3.3
144 0
IC4403 1 4.3
20
3 0.7
4 0.3
5 1.5
6 2.0
70
80
90
10 0
11 (2.1)[0]
12 (0)[2.1]
13 2.3
14 (0)[4.2]
IC4404 1 0.2
20
30
4 3.0
5 3.3
IC4405 I 8.8
G0
O 5.0
Q4105 B 4.3
C0
E 4.9
Q4106 B (2.1)[3.0]
C (0)[4.9]
E (1.4)[2.3]
Q4107 B 0.8
C0
E 1.4
Q4108 B (3.5)[0]
C (0)[4.9]
E0
Q4109 B 0.3
C 4.9
E0
Q4110 B 4.4
C (0.1)[0.3]
E 4.9
Q4111 B 4.9
C0
E 4.9
Q4112 B (0.13)[0]
C 4.9
E 0.1
Q4113 B 0.3
C0
E 0.9
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
Q4114 B 1.8
C0
E 2.4
Q4115 B 1.7
C0
E (0)[2.4]
Q4116 B 1.8
C0
E 2.4
Q4117 B 1.6
C0
E 2.3
Q4118 B 0.3
C 2.4
E0
Q4119 B 0.9
C0
E 1.6
Q4120 B 0.7
C0
E 1.4
Q4121 B 0.7
C0
E 1.4
Q4122 B 2.9
C 4.9
E 2.3
Q4123 B 2.9
C 4.9
E 2.3
Q4124 B 2.9
C 4.9
E 2.3
Q4125 B 4.4
C0
E 4.9
Q4126 B 2.4
C0
E 3.0
Q4127 B 2.6
C0
E 3.2
Q4128 B 2.6
C0
E 3.2
Q4129 B (2.2)[0]
C 8.1
E 1.6
Q4130 B 2.4
C 8.1
E 1.8
Q4131 B 2.4
C 8.1
E 1.8
Q4132 B (0)[8.1]
C 2.9
E 8.7
Q4133 B 8.1
C 3.0
E 8.7
Q4134 B 8.1
C 3.0
E 8.7
Q4135 B (2.1)[0]
C 8.1
E 1.5
Q4136 B 2.6
C 8.1
E 2.0
Q4137 B 0
C 8.1
E 2.0
Q4138 B 8.1
C 3.0
E#
Q4139 B 8.1
C 4.0
E 8.7
Q4140 B 8.1
C 3.2
E 8.8
Q4141 B 3.0
C 8.7
E 2.4
Q4142 B 4.0
C 8.7
E 3.3
Q4143 B 3.3
C (8.7)[0]
E 2.7
Q4144 B 4.8
C0
E 4.9
Q4145 B 0.2
C 4.8
E0
Q4201 B 2.9
C 4.9
E 2.3
Q4202 B 3.0
C 4.9
E 2.4
Q4203 B 3.0
C 4.9
E 2.4
Q4204 B 2.0
C 4.9
E 1.3
Q4205 B 2.1
C 4.9
E 1.5
Q4206 B 2.1
C 4.9
E 1.5
Q4207 B 3.3
C 4.5
E 2.9
Q4208 B 1.9
C 3.2
E 1.3
Q4209 B 3.3
C 4.6
E 3.0
Q4210 B 1.9
C 3.2
E 1.3
Q4211 B 1.0
C 3.2
E 0.3
Q4212 B 0
C 3.3
E0
Q4213 B 0
C 4.9
E 0.2
Q4214 B 0.2
C 4.9
E 0.3
Q4215 B 0.4
C0
E 1.0
P5 BOARD VOLTAGE LIST (EXCEPT KV-AR34M60)
