Sony TRINITRON KV-AR34M3 - Page 77

– 90 –
KV-AR34M36/AR34M64/AR34M66/AR34M94
RM-993
KV-AR34M60
RM-995
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
P5 BOARD VOLTAGE LIST (EXCEPT KV-AR34M60)
Ref Pin No. Voltage[v]
Q4216 B 1.3
C0
E 1.9
Q4217 B 1.3
C0
E 1.9
Q4218 B 3.2
C 4.9
E 2.6
Q4219 B 3.2
C 4.9
E 2.6
Q4401 B 1.0
C0
E 1.6
Q4402 B 0.4
C0
E 1.0
Q4403 B 0.4
C0
E 1.0
Q4404 B 0.9
C0
E (0)[1.5]
Q4405 B 0
C0
E 1.5
Q4406 B 1.4
C0
E 2.1
Q4407 B 3.0
C0
E 3.6
Q4408 B 0
C (0)[4.9]
E0
Q4409 B 3.3
C0
E (2.1)[*]
Q4410 B 5.0
C 4.9
E 4.3
Q4413 B 2.9
C0
E 3.5
Q4414 B 2.2
C 2.9
E 1.6
Q4415 B (0.1)[0.7]
C 1.6
E 0.1
Q4416 B 0.1
C0
E 0.7
Q4417 B 3.4
C 5.0
E (3.8)[2.8]
Q4418 B (0)[0.7]
C 1.6
E 0.1
Q4419 B 1.6
C0
E 2.2
Q4420 B (0)[0.3]
C0
E 0.1
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
DH BOARD VOLTAGE LIST (EXCEPT KV-AR34M36)
Ref Pin No. Voltage[v]
IC3805 1 4.8
2 5.2
3 2.8
4 2.8
50
6 2.8
7 2.8
8 2.8
9 2.4
8 7.1
IC3807 1 12.2
20
3 2.5
4 1.2
50
60
7 4.9
80
Q3807 B 0
C 4.8
E0
Q3808 B 4.8
C 0.1
E0
Q3809 B 0.1
C 1.3
E0
Q3810 B 2.5
C0
E 3.2
Q3811 B 3.2
C 7.2
E 2.6
Q3812 B 0.1
C 2.8
E 1.3
Ref Pin No. Voltage[v]
IC3901 1 (4.9)[4.8]
2 (0)[4.9]
3 (4.8)[0]
Q3901 B 0.1
C 4.9
E 0.2
Q3902 B (4.7)[0]
C (2.4)[4.9]
E (2.0)[0.1]
H1/H2 BOARD VOLTAGE LIST
D2 BOARD VOLTAGE LIST
Ref Pin No. Voltage[v]Ref Pin No. Voltage[v]
Ref Pin No. Voltage[v]
IC2801 1 5.7
2 6.3
3 6.3
40
5 6.4
6 6.3
70
8 14.8
IC2805 1 0
20
30
40
5 4.4
6 4.4
7 4.4
8 4.4
Q2802 B 1.6
C0
E 2.3
Q2805 B 1.6
C0
E 1.6
Q2806 B 1.6
C 8.1
E 1.6
Q2807 B 1.4
C0
E0
Q2811 B 5.7
C0
E 5.5
Q2813 B 2.3
C12
E 1.8
Q2822 B 11.5
C 12.1
E 3.3
Q2823 B 3.3
C 12.1
E 2.7
